CNC Xyz 2030

Specifications

Features of CNC Router XYZ 2030

1. Strong welded tubular steel frame that keeps lathe bed of wood working machine in shape.
2. Y axis of our woodworking CNC Router is equipped with double motors to keep stable moving.
3. Speedy and accurate Rack Rail travel method.
4. Imported Square Liner Rail with high accuracy and heavy burthen.
5. Advanced vacuum with double cavities.
6. Humanized design of lathe bed vacuum that is easy to operate.
7. Intelligent protecting system that protect wood working machine from damages resulted from false operation.

Description

1.X, Y, Z working area 2000 X 3000 X 200 mm
2.X, Y Movement Rack and Pinion transmission, Linear Square orbit (Taiwan Hiwin).
3.Z - Movement Imported ball screw made in Germany Linear Square orbit (Taiwan HIWIN)
4.Resolution Working Accuracy w air cooled HSD Italy Power MoReposition Accuracy
                  0.01 mm
                  0.05 mm
5.Machine Bed Structure Welded Steel / Cast Steel structure
6.Bed Type T Slot + Vacuum
7.Max. idling speed 50 m/min
8.Spindle Type 3.0,4.5kw water cooling / 3.0, 6kw air cooled HSD Italy
9.Spindle speed 0-24000 rpm / 0-18000 rpm
10.Working voltage Three Phase 380V/50Hz
11.Inverter Delta Taiwan
12.Drive Motors Stepper
13.Max. Power (without spindle) 1850 W
14.Max. Working Speed 25,000 mm/minute (good quality cutting bits ensured)
15.Command G code, HPGL, U00, mmg, plt
16.Operating system DSP/ Mach3/ NC Studio
17.Interface USB
18.Diameter of cutter Ø3.175-Ø12.7
19.Dust collector (complete) Yes
20.Work-holding T Slot + By suction (vacuum)
21.Guarantee: One year from the date of commissioning
