Specifications
Portable mini acrylic,wood,glass laser engraver1.Auto focus
2.80mm up-down
3.40W,60W Laser tubes
4.Engraving Speed 1200mm/s
Small size table top laser engraver for acrylic,glass,wood,MDF
EXLAS-Smart-3040
EXLAS-Smart-3040 Portable laser engraver
EXLAS-Smart laser engraver is presented in table form. This series laser engraving machines are small in size but versatile and powerful in functionality. This mini laser engraver is easy to use and does not require a separate room. EXLAS-Smart laser engraving machine also has a resolution of 1000 dpi, which allows handling the details with great precision and performing high-quality laser engraving of small images. This laser machine is equipped with a 40w laser tube and can handle any non-metallic surfaces, such as wood, glass, plastic, stone (natural and artificial), rubber, textiles, leather, etc.
In addition, the power of the laser beam can be adjusted, which allows the laser engraver to handle a variety of materials without damaging them. This desktop laser machine is also equipped with a lifting table and colored thinker PC top cover that protects the operator from the laser radiation. The laser engraver does not require conversion of the premises, and can be placed in an office or small workshop.
Other Standard Models
Model | Working area | Laser tube |
EXLAS-6040 | 600 X 400 mm |
40W-60W-80W-100W-150W-180W. |
EXLAS-9060 | 900 X600 mm | |
EXLAS-1280 | 1200 X 800 mm | |
EXLAS-1410 | 1400 X 1000 mm | |
EXLAS-1613 | 1600 X 1300 mm |
Parameters
Working range | (11.811"x 15.75")300x400mm |
Material height | (0.59")15mm |
Machine dimensions | (33.86"x32.28"x16.23") 860x820x430 mm |
Packing dimension | (34.25"x32.68"x18.90") 870x830x480 mm |
Gross weight | 55kg |
Max engraving speed | (47.2in/s)1,200mm/s |
Max cutting speed | (15.7in/s)400mm/s |
Safe Laser Operation | Due to its unique enclosure design, door safety switches, water-cooling safety switches, temperature safety switch, the EXLAS-smart is certified Laser Safety Class 2. It can operate safely in any production environment. |
Laser-type | Hermetic and detached CO2 glass laser tube |
Laser-power ranging | 40W,60W |
Focal Length Lenses | 38.1 mm( 0.125") |
Autofocus | |
Cooling mode | Circulating-water-cooling (Special industrial chiller for option) |
Exhaust Systems | Each machine configured standard with EXHAUST FAN & PIPES, airtight structure ensure the fume exhausting more exhaustive |
Power adjusting | 10-100%controlling,no segment and adjusting by software |
Machine control and drive | Speedy DSP controlling with USB port, stepper |
software | Original English laserCut software & dongle, Print Driver Software (Notepad,Word, ill. CorelDraw,AutoCAD, etc.) |
Repeating location | ±0.01mm |
Minimum Character | Chinese character 2.0mm, christcross-row 1mm |
Motorized lifting table range (up-down) | (3.15")80mm |
Working voltage | AC220V/120V 50/60HZ |
Working environment | Temperature: 0-45°C,Humidity: 5%-95%,and congeal-water removed |
Software language | English (Modifiable by editing the language package file) |
Dictate format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, etc. |
