GOOD Price with CE CO2 Glass Tube Mini Laser Engraving Machine Table-top YKL-3040
Machine Description | EXLAS 3040 mini laser machine |
Engraving area | 400*300mm |
Packing dimension(L*W*H) | 720*680*450mm |
Gross weight | 50kg |
Laser-type | Hermetic and detached CO2 laser tube |
Cooling mode | Circulating-water-cooling (Special water-cooling chiller for option) |
Power adjusting | 0-100%controlling,no segment and adjusting by software |
Machine control and drive | Speedy DSP controlling, stepper motor |
Max engraving speed | <36,000mm/min |
Max cutting speed | <12,000mm/min |
Repeating location | ±0.01mm |
Minimum Character | Chinese character 2.0mm, christcross-row 1mm |
software | LaserCut |
Adjustable up-down distance of laser head | 30mm |
Material-feeding thickness | 30mm+up-down range 80mm |
Working travel area | 300*500mm |
Up-down range of working table | 80mm |
Working voltage | AC220V 50HZ |
Working environment | Temperature: 0-45°C,Humidity: 5%-95%,and congeal-water removed |
Controlling software language | Simplified Chinese, complicated Chinese, English |
Dictate format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Supporting AutoCAD, CoreDraw direct outputting |
Applicable Industries:
The machine is suitable for industries such as billboards, artistic gift, crystal ornaments, paper-cut engraving, bamboo embossment, printing, garments and leather industries, embroidery, interior decoration and frame fabrication, etc.
Applicable materials:
Non-metal materials such as double-color sheets, acryl, glass, wood planks, paper, leather, rubber, marble, granite and tiles, etc.
Showcase:
