XYZ-CAM Four Axis 3D CNC Router resin, foam, wood P4-1325
- 10 Set / Sets per Month
- Qingdao
- T/T
- engraving cnc router,1325 woodworking cnc router 1300*2500*200
- engraving and milling machine,1325 woodworking cnc router 1300*2500*200
- engraver router,1325 woodworking cnc router 1300*2500*200
- dsp control cnc machine,1325 woodworking cnc router 1300*2500*200
- cnc woodworking router machine,1325 woodworking cnc router 1300*2500*200
- cnc woodworking router,1325 woodworking cnc router 1300*2500*200
Product Details
Condition: | New | CNC or Not: | CNC | Place of Origin: | Shandong, China |
Brand Name: | XYZ-CAM | Model Number: | XYZ-CAM-P4-1325 | Voltage: | AC380V/50Hz,3PH |
Power(W): | 18.0kw | Certification: | ISO,CE,FDA,GOST-R | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
4 Axis CNC Router for 3D model/Mould1. Angle head+C aixs
2. Horizontal machining
3. True 3D work/side milling/drilling.
Heavy Duty 4 Axis CNC Router for 3D Mould/Model industry XYZ-CAM-P4-1325
(Certificate: ISO,CE,FDA,GOST-R)
4 Axis CNC Router for 3D Mould/Model industry:
1) Italian-made spindle & Angle head + Axis
2) Auto tool changing with Carousel Magazine
3) Advanced 4 Axis controller system
4) 1.3KW YASKAWA SERVO with planetary reduction gears
Standard Models of 4 Axis CNC Router for 3D Mould/Model industry:
Model | Working area |
The Z travel can be built from 500-1000mm. Customization is available. |
XYZ-CAM-P4-1325 | 2500X1300X500 MM | |
XYZ -CAM-P4- 1530 | 3000X15000X500 MM | |
XYZ -CAM-P4- 2030 | 3000X2000X500 MM | |
XYZ -CAM-P4- 2040 | 4000X2000X500 MM |
Belief Introduction of 4 Axis CNC Router for 3D Mould/Model industry:
1.XYZ-CAM-P4-1325 CNC router , incorporates a 9.5kw Italian-made ATC spindle and 90° angle head with C Axis, it is a combination for both three axis vertical machining and the horizontal machining by C Axis (4th Axis). The machine is capable to finish a true 3D structure in a single setup. The ideal material for this machine including foam, wood, plastics, composite resin….
2. With Precision machined & heavy duty frame, stress relieved in a rigorous thermal treatment, hence, the P4 4 Axis CNC is allows a 500-1000mm large Z travel, and offers accurate and smooth machining effect without vibration.
3. Motion by helical rack and gear on X and Y, imported high-precision ball screw on Z Axis, which moving smoothly, to ensure the machine’s high precision.
4. High-performance Japanese Yaskawa servo system with planetary gear reducers to ensure the machine’s high speed and accuracy.
5. Advance 4 Axis control system, auto-complete multilevel 3D processing, carving or cutting. Meanwhile, offline operation can be realized.
6. Original industrial standard HSK tool holders, Taiwan made Carousel tool magazine with 8 positions plus T9 the angle head position.
7. Standard configuring with auto lubrication system, automatic tool setting system.
8. Top quality accessories, to minimize the machine’s failure rate,Well-known electrical parts Schneider, Omron, Honeywell, etc., Pneumatic components Taiwan AirTAC.
Applicable Industries of 4 Axis CNC Router for 3D Mould/Model industry:
The machine is capable to finish a true 3D structure in a single setup. The ideal material for this machine including foam, wood, plastics, composite resin…. 3D models, moulds, animated advertising and decorative elements, theme parks, Arcade Games
Technical Parameters of 4 Axis CNC Router for 3D Mould/Model industry:
No. | Description | Parameter |
1 | X,Y,Z, C Working Area | 2500x1300X500mm X 360° |
2 | Table Surface | Vacuum and T-slot Combined |
3 | Frame | Heavy duty big Steel Tube welded Structure (stress relived by heat treatment) |
4 | X, Y Structure | Helical Rack and Pinion Drive, Hiwin Rail Linear Bearings |
5 | Z Structure | TBI Ball Screw and Hiwin Rail Linear Bearings |
6 | Max. Power Consumption | 18Kw (full load) |
7 | Max velocity | 40 m/min |
8 | Max working speed | 18m/min |
9 | Spindle Rotating speed | 0-24.000 r/min |
10 | Max speed of Angle heads | 10.000r/min |
11 | Processing accuracy | ±0.05mm |
12 | Repeat accuracy: | ±0.02mm |
13 | Working Voltage | AC380V/50Hz,3PH |
14 | Command Language | G Code |
15 | Operating System | SYNTEC, SIEMENS, OSAI, Weihong, for option |
16 | Computer Interface | CF card, Ethernet |
17 | Tool holders | HSK F63 |
18 | Tool magazine | Carousel style 8 or 12 positions |
18 | Software | Powermill software |
19 | Max. Power Consumption | 18Kw (full load) |
20 | Running Environment | Temperature 0 - 45 Centigrade Relative Humidity 30% - 75% |
Packing& Shipment
Long Term Cooperated shipping forwarder to offer shipment.
Standard export package, custom suffocating free.
Service
Engineers available to service machinery overseas…
Remote assistance, support online, by call, by video, by e-mail...
About US
Jinan XYZ Machinery LLC has been manufacturing CNC Router and laser machines over 10 years.With the constant technical innovation, we have developed CNC machines- the XYZ series CNC Router under XYZ-CAM, XYZ-S, XYZ-V brands, and Laser cutting/engraving machines under YKL, EXLAS, and XYZL brands.
We are proud to be supplying now over 100 countries worldwide and many other regions around the globe. Customers purchase with confidence due to our unique and innovative designs. Each machine is produced in house by qualified technicians and a well trained staff to serve your needs, all delivered on a timely basis with pride.
