Higher Efficiency SRB for Hydraulic Tube

FOB Price

US$ 1.2 - 1.5 / Metric Ton

20 Metric Tons(Min. Order)

Port Yantai/Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Thickness	2, 30	Section Shape	Round
Outer Diameter	30 - 280 mm	Place of Origin	Shandong, China
Secondary Or Not	Non-secondary	Application	Hydraulic Pipe
Technique	Cold Drawn	Certification	Other, ISO 9001 2008
Surface Treatment	Other, According to the custome's need	Special Pipe	API Pipe
Alloy Or Not	Non-alloy

Product Description

Specifications

Higher efficiency SRB for hydraulic tube
Quality confirming to International Standards
Material Test Certificates fo

Higher efficiency SRB for hydraulic tube
1.Higher efficiency
2.Higher accuracy
3.Better Quality
4.More competitive price

Our Advantages:
· Fast delivery
· Non-standard sizes and made-to-order
· Small min order quantity
· Economical Pricing
· Quality confirming to International Standards
· Material Test Certificates for Quality Assurance
· Technical Qualified After Sales
· Excellent Delivery Conditions

Usage

Applicable to hydraulic pressure, pneumatic cylinder,oil pump barrel, motor body, transmission shaft, etc.

Quality Standard

DIN 2391, EN 10305-1, SAE J524, ASTM A519 and GB3639

Process

Raw materials- Cold drawn/rolled- Heat treatment(BKS)- Honed or SRB- packing

Steel Grade

ST52, ST52.3, E355, SAE1026, Q345B.

*Low temperature impact test upon request (27J/-20°C).

Size

Processing	Cylinder diameter	Length /mm	Straightness	Size accuracy	Wall thickness/mm	Inner boreroughness
Cold Drawn/Rolled	ID28~OD400	≤12M	0.3~1.0m m/m	H8-H11	±5%	0.8~1.6um
Honed/SRB	ID30~OD500	≤12M	0.3~1.0m m/m	H8	±5%	0.4~0.8um

Inner hole size tolerance

ID size	ID deviation (mm)
ID size	H7	H8	H9	H10
30	0.021	0.033	0.052	0.084
>30~50	0.025	0.039	0.062	0.1
>50~80	0.03	0.046	0.074	0.12
>80~120	0.035	0.054	0.087	0.14
>120~180	0.04	0.063	0.1	0.16
>180~250	0.046	0.072	0.115	0.185
>250~315	0.052	0.081	0.13	0.21
>315~400	0.0527	0.089	0.14	0.23

Packing

With anti-rust oil on inner diameter of each pipe,tube caps on both ends, hexagonal bundles of max 3,000 kg with several steel strips, nylon bag and waterproof paper package each bundle. Of course, customers can customize other packing way.

If any requirement or question , please feel free to contact us!
