Help CenterSt52 Cost Effective Cylinder Seamless Precision Steel Tube
Related Products
-
the Best Manufacture of Telescopic Cylinder Precision Seamless Cold Finished Steel TubeUS$ 0.5 - 1.5MOQ: 5 Metric Tons -
St52.3 High Precision Pickling Low Carbon Seamless Steel PipeUS$ 0.5 - 1.5MOQ: 5 Metric Tons
-
Precision Seamless Steel Pipe and Tube for Hydraulic and Pneumatic CylinderUS$ 0.5 - 1.5MOQ: 5 Metric Tons
-
Ck20 Seamless High Precision Steel Tube for AutomobileUS$ 0.5 - 1.5MOQ: 5 Metric Tons
-
SAE1026 Precision Seamless Steel Tube With Smooth SurfaceUS$ 0.5 - 1.5MOQ: 5 Metric Tons
ABOUT OUR PRODUCT
Product name |
st52 Cost effective cylinder seamless precision steel tube | |
Size |
OD |
30-250mm |
WT |
2-30mm |
|
Length |
1-6m or according to the customer’s need |
|
Material |
20#,45#,16Mn,10#,st35-st52,25Mn |
|
Surface treatment |
According to the customer’s acquirement |
|
Ends |
1. Bundle packing. 2. Beveled end or plain end or vanished as buyer's required. 3. Marking: as per customer's requests. 4. Painting varnish coating on the pipe. 5. Plastic caps at ends. |
|
Section shape |
Round |
|
Application |
Used For Hydraulic equipment ,mechanical structures ,automotive parts,oil drilling |
|
End protector |
With plastic caps or not |
|
Inspection |
With Hydraulic Testing, Eddy Current, Infrared Test ,ultrasonic Test |
|
payment |
1.T/T:30% T/T advance, 70% balance copy of B/L 2.L/C:at sight 3.T/T and L/C:30% T/T advance, 70% L/C at sight.etc |
|
contact |
Yantai Xinpeng Steel pipe . Http:// Tel:86-535-6835398 Fax:86-535-6835383
|
|
ABOUT SOME DIMENSIONS
40*50 |
90*110 |
140*170 |
190*215 |
40*55 |
95*110 |
145*170 |
190*220 |
50*60 |
95*115 |
150*170 |
190*225 |
50*65 |
100*110 |
150*175 |
200*220 |
55*70 |
100*114 |
150*180 |
200*225 |
60*70 |
100*115 |
155*180 |
200*230 |
60*75 |
100*120 |
160*175 |
200*245 |
60*78 |
100*125 |
160*180 |
200*250 |
63*73 |
105*125 |
160*185 |
220*250 |
63*75 |
110*125 |
160*190 |
220*270 |
63*76 |
110*130 |
160*195 |
225*250 |
63*78 |
115*130 |
165*190 |
240*273 |
65*80 |
115*135 |
165*205 |
250*290 |
70*80 |
120*140 |
170*200 |
250*300 |
70*82 |
125*140 |
180*200 |
260*300 |
70*85 |
125*145 |
180*205 |
280*323 |
70*90 |
125*150 |
180*210 |
280*355 |
75*90 |
130*150 |
180*215 |
300*350 |
80*92 |
130*155 |
180*220 |
200*213 |
80*95 |
130*160 |
185*205 |
200*216 |
80*100 |
135*160 |
185*215 |
250*266 |
85*100 |
140*160 |
185*220 |
|
90*105 |
140*165 |
190*210 |
|
THE TOLERANCE OF DIMENSION
OD |
GB/T3639(GB8713) |
DIN2391(EN10305) |
Our Tolerence |
Best Quality |
4-30mm |
±0.10mm |
±0.08mm |
±0.05mm |
±0.02mm |
31-40mm |
±0.15mm |
±0.15mm |
±0.05mm |
±0.03mm |
41-50mm |
±0.20mm |
±0.20mm |
±0.05mm |
±0.03mm |
51-60mm |
±0.25mm |
±0.25mm |
±0.08mm |
±0.03mm |
61-70mm |
±0.30mm |
±0.30mm |
±0.10mm |
±0.05mm |
71-160mm |
±0.30mm |
±0.30mm |
±0.10mm |
±0.05mm |
Tolerance in WT |
±0.12mm |
±0.10mm |
±0.05mm |
±0.03mm |
Process |
Diameter |
Length |
Precision |
Inner Hole Roughness |
Cold Rolled |
30-100mm |
≤12 m |
H8-H10 |
0.4-1.6 |
Cold Draw |
30-250mm |
≤12 m |
H8-H10 |
0.8-1.6 |
Honing |
40-500mm |
≤12 m |
H8-H9 |
0.4-0.8 |
Rolling |
40-400mm |
≤7 m |
H8 |
0.4 |
|
|
|
|
|
Inner Diameter |
H8 |
H9 |
H10 |
|
30mm |
±0.033 |
±0.052 |
±0.084 |
5-30mm |
30-50mm |
±0.039 |
±0.062 |
±0.100 |
±0.080 |
50-80mm |
±0.046 |
±0.074 |
±0.120 |
|
80-120mm |
±0.054 |
±0.087 |
±0.140 |
|
120-180mm |
±0.063 |
±0.100 |
±0.160 |
|
180-250mm |
±0.072 |
±0.115 |
±0.185 |
|
250-315mm |
±0.081 |
±0.130 |
±0.210 |
|
315-400mm |
±0.089 |
±0.140 |
±0.230 |
|
ABOUT OUR COMPANY
we are the top 5 manufacture of precision seamless steel tube in China ,we have passed ISO 90012008 verified certification ,our company mainly produces various specifications cold finished steel tube which are widely used in hydraulic cylinder ,automobile ,oil drilling ,textil machinery ,engineering machinery ,and so on .if you are interested in our product ,welcome to our company to visting and negotiate business .
ABOUT OUR CERTIFICATE
ABOUT OUR PACKAGING
packaging details: standard packing with plastic caps and starpped bundles,standard wheight approx 1500Kg
delivery details: 15 days after receiving downpayment or L/C or as your request
