WF-DS018 Wind Barrier for Coal Pile

wind barrier for coal pile

The steel wind barrier, dust suppression system is mainly used in areas that face the problem of air pollution, including bulk storage yard, road and railway, sport court, sandy areas and field operation areas. With constantly research and development of steel wind barrier, dust suppression system, applications are

continuously expanding.

Our steel wind barrier and dust suppression wall is eco-friendly, which has been identified by the environmental protection department. According to China's regulations on environmental protection, sewage charges will be impugned on excessive dust. Meanwhile, dust pollution will affect the surrounding area where people live, learn and work. After the steel wind barrier and dust suppression wall system is installed, dust pollution can be greatly reduced. The working and living environment for nearby residents can be greatly improved. It redecorates the landscape of surrounding areas and converts the previously polluted stock dump into a green yard achieving its purpose as dust pollution regulator.

wind barrier and dust suppression system design content

 1. General layout design

The wind barrier and dust suppression wall can be installed all around the storage yard, or just in the strongest upwind direction. Green Technology has also three-side system available. The system will be designed according to size and shape of the yard, local wind direction, wind frequency and other weather

conditions.

The best distance between the wind barrier and dust suppression wall and the stock pile has to be equal to two or three times its height (stock pile). For the storage yard composed of multiple piles, the wind barrier can be placed based on local conditions. Generally speaking, it can be installed along the edge of the stock pile.

During actual construction, we should not only consider natural conditions, but also keep in mind the field conditions. The on-site investigation mainly includes the survey of constructions, mechanical equipment, underground pipelines, roads and other facilities in the yard. Only by doing the deep investigation on the field conditions can we ensure that the construction of our wind barrier and dust suppression wall will not affect the normal operation of the storage yard and function of its auxiliary facilities.

2. Height design

The height of the wind barrier and dust suppression wall mainly depends on stacking height, generally 1.1 to 1.5 times the height of the stock pile. When determining the height, we should also take into account the yard size to make sure that the stack materials can be well protected within the scope of effective shelter.

3. Steel structure design

The steel structure design of wind barrier mainly includes the overall structure design, steel bar sizing and selection, connection scheme, support bar and frame design, as well as the steel temperature joint design. When designing the steel structure of the wind barrier and dust suppression wall, we should calculate equivalent static wind pressure and make a static analysis of the stress and displacement. For the large-scale yard, coming with a length of more than one kilometer and a height of more than ten meters, we have to further study the dynamic load, resistance coefficient, vibration and other security issues.

4. Foundation design

When doing the foundation design of wind barrier and dust suppression wall, we should determine the structure type and cross-section dimensions. In addition, it also includes the design of reinforcement bar and deformation joint.

 Examples of our wind barrier projects

Company Information

Green (Tianjin) Technology Development Co., Ltd. locates in Baodi Jiuyuan Industrial Park with the registered capital of ten million U.S. dollar. Green Technology specializes in the R & D, production and installation of wind, sand, snow and dust control systems. The daily output of steel windbreak and dust suppression panel is over 3,000 square meters. Green Technology is supplying a scientific and effective windbreak and dust/sand/snow suppression solution for the ports, terminals, power plants, cement factories, coal mines, roads, railway, agriculture and other fields that face these problems.
