OEM Plastic Injection Tube Mold Maker

FOB Price

US$ 1,000 - 20,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Specification:

plastic injection tube mold

Long mold life

Good part design and mold design

Competitive prices

plastic injection tube mold detailed in following :

Cavity/Core Material	P20, 718,2738,H13,DIN1.2311,DIN2344
Product Raw Material	ABS/PP
Cavity	Single cavity/Multi Cavity
Cycle Time	15S
Runner System	Hot runner, Cold runner
Finish	Good Polishing
Mold Guarantee	More than 500,000SHOTS
Mould standard	HASCO, DME, or by requested etc.
Software	CAD, Pro-E, UG, Solidwork
Tolerance	± 0.02mm
Main Technique	Milling, Grinding, CNC , Engraving ,EDM, Wire-cutting etc.
Packing	Wooden Case

1.Quote	According Sample or 2D/3D drawing or Picture with detailed information , If the part some design is not good , we will give suggestion and solutions to customer
↓
2.Discussion	Mold material, cavity number, price, runner, payment, etc.
↓
3.Approved	Order confirmed
↓
4. Advance	Pay 50% by T/T
↓
5.Product Design Checking.	We will send 2D and 3D part drawing and PPT file for customer check
↓
5.Mould Design	According the Approved Part drawing , we will make the mold design and send to customer confirm
↓
6.Mold Steel Material and Component Prepare	After drawing confirmed , we will start to prepare the steel material and standard components
↓
7.Mold Processing	Send detailed reports with pictures to customer each week
↓
8.Mold Testing	Send Test samples with report to customer
↓
9. Mold Modification	According to customer’s feedback
↓
10.Balance settlement	50% by T/T after the customer approved the test sample and mould quality.
↓
11.Packing and Delivery	Each Mold will be packing with some damageable spare parts , and send detailed pictures to customer

Q/C Inspect Moulds:

1.Mould Material Q/C

- Mould Steel Checking(Hardness, Crack ,Blow hole material defects )

- Mould Standard Spare Parts Checking(hardness, size, flaw checking)

2. Mould Machining Process Q/C

- Design checking (Part design, mould design,Including 2D drawing and 3D drawing)

- Each part of mould’s size checking after machining according to 2D drawing

- Mold Test (check mould running conditions and T1 samples)

3.Make sure to follow and checking each points of customer’s request before shipment
