Home > Lights & Lighting > LED Outdoor Lighting > LED Street Light > 56w/112w/168w High Lumens AC85v-265v Led Street Light

56w/112w/168w High Lumens AC85v-265v Led Street Light

Name: 56w/112w/168w High Lumens AC85v-265v Led Street Light
Brand: SYNNO or OEM
SKU: 123023119

56w/112w/168w High Lumens AC85v-265v Led Street Light thumbnail-1

56w/112w/168w High Lumens AC85v-265v Led Street Light thumbnail-2

56w/112w/168w High Lumens AC85v-265v Led Street Light thumbnail-3

56w/112w/168w High Lumens AC85v-265v Led Street Light thumbnail-4

56w/112w/168w High Lumens AC85v-265v Led Street Light thumbnail-5

56w/112w/168w High Lumens AC85v-265v Led Street Light photo-1

56w/112w/168w High Lumens AC85v-265v Led Street Light photo-2

56w/112w/168w High Lumens AC85v-265v Led Street Light photo-3

56w/112w/168w High Lumens AC85v-265v Led Street Light photo-4

56w/112w/168w High Lumens AC85v-265v Led Street Light photo-5

US$ 100 - 280 MOQ: 5 Sets

Key Specifications

Get Latest Price

LED Light Source:

LED

Input Voltage(V):

85-265

Lamp Power(W):

112

Contact Supplier Request Quote Chat Now

Jiangmen Synno Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Jiangmen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source LED

Input Voltage(V) 85-265

Lamp Power(W) 112

Lamp Luminous Flux(lm) 11200

Lamp Luminous Efficiency(lm/w) 100

Color Temperature(CCT) Cool White

Working Temperature(℃) -40, 55

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP65

Certification CE

Warranty(Year) 3

Place of Origin Guangdong, China

Brand Name SYNNO or OEM

Model Number SL-ST-ST6-112W

Specifications

led street light
1.LED Power: 56/112/168*1W
2.Initial flux:100-110lm/W (PW)
3.Input Voltage:AC85V~265V
4.Power Factor:>0.98

56w/112w/168w high lumens AC85v-265v led street light

LED street light Characteristic

OPTICAL	LED Power Consumption	56X1w	112X1w	168X1W
	System Power Consumption	70w	130w	180W
	LED Initial Flux	100lm-110lm/per watt (*Pure White 6000K-6500K)
	Lamp Maintain Flux *(After the lens and thermal stabilization)**	75lm-85lm/per watt (*Pure White 6000K-6500K)
	Illumination (Enadir) (LED Power=168W PW6500K)	Mount Height= 6M : >102lux Mount Height= 8M : >57lux Mount Height= 10M : >37 lux Mount Height= 12M : >26 lux
	CRI	WW: Ra>60 PW:Ra>70
	Light Distribution Curve	Asymmetric (Bat Wing)
	Beam Angle	140 Degrees
	Light Decay	< 15% (20,000 hours)
ELECTRICAL	Input Voltage	AC85V-AC265V, AC277V+ (50Hz-60Hz)
	Working Voltage	36VDC
	TJ	60 °C ±10 %
	Lamp Efficiency	>88%
	Power Factor	>0.95
	IP Grade	IP65
MECHANICAL	Dimensions	L76W32H7.5cm(112W)
	Net Weight	10.5KG±5 %(112W)/7.5KG±5 %(56W) 13.5KG±5 %(168W)
	Material	Aluminum Alloy
	Working Environment	Temp: -40°C ~ 55°C Humid:10%-90%
	Dimension of pipe for installation	Φ62mm

Description

ST6 LED Street Lights are mainly used in street, roadway, bridge, housing project, public park, parking lot, yard and other facilities with need of high-brightness general illumination during the night.

Features

Green and Environmental Protection: no lead, no mercury, no environmental pollution;
Universal Input Voltage-85-264vAC full voltage range constant, constant-current PWM technology, high efficiency, low-heat, high-precision constant current;
No Pollution to Power Network: Power factor ≥0.9, THD≤20%, EMI apply with the global universal index, reduce the power loss and transmission lines to avoid contamination of the network of high frequency interference;
Work under Low-voltage and Low-Heat, Safe and Reliable: LED junction temperature can be controlled under an ideal temperature (TJ<60°C Ta=25°C ambient temperature);
Environmental friendly and energy-saving. Contains no mercury or lead. Consume 50%-70% less power than HID street light

Packaging

1pcs/CTN or 4 pieces foams inside.

Payment Mathod:

1.Paypal

2.Credit Card

3.Wire Transfer

4.West Union

5.L/C 30% advance; Balance on fax copy of BOL

Shipping Mathod and Shipping time.

1. Shipping by EXPRESS:Sample can be delivered within 2-5 days on customer request, around 5-7 working days to arrive;

2. Shipping by SEA : Big order can be delivered within 10-25 days on customer request,

After-sales Policy:

There are two-year guarantee for the inserted driver of the light and three-year guarantee for the led source on the condition of the light being used under the normal environment, suitable maintenance and storage; any abnormal using is without guarantee. We can provide the repair, exchange (the components and parts) or replacement with a new item. The three schemas are for your option. Exceeding the guarantee time, appropriate cost for the material and the labor should be charged.

Pictures and Label Policy

We offer free pictures with your logo if you have experience in our store. We also accept change label business. Custom label's minimum order quantity is 300, it cost USD50.
