56W/112W/168W Pure White Street Led Lights

Name: 56W/112W/168W Pure White Street Led Lights
Brand: SYNNO
SKU: 123023243

US$ 100 - 380 MOQ: 5 Sets

Key Specifications

LED Light Source:

112W

Input Voltage(V):

AC85-265V

Lamp Power(W):

120

Jiangmen Synno Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Jiangmen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source 112W

Input Voltage(V) AC85-265V

Lamp Power(W) 120

Lamp Luminous Flux(lm) 11200

Lamp Luminous Efficiency(lm/w) 110

Color Temperature(CCT) Pure White

Working Temperature(℃) -30, 50

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP65

Certification CE, EMC, UL, VDE

Warranty(Year) 3

Place of Origin Guangdong, China

Brand Name SYNNO

Model Number SL-ST-ST6-112W

Specifications

1.LED Power:56/112/168W
2.Lamp Maintain Flux:100-110lm/w(PW)
3.Input Voltage:AC85~265V
4.Power Factor:>0.9
5.IP65

56W/112W/168W street led lights

OPTICAL	LED Power Consumption	56X1w	112X1w	168X1W
	System Power Consumption	70w	130w	180W
	LED Initial Flux	100lm-110lm/per watt (*Pure White 6000K-6500K)
	Lamp Maintain Flux *(After the lens and thermal stabilization)**	75lm-85lm/per watt (*Pure White 6000K-6500K)
	Illumination (Enadir) (LED Power=168W PW6500K)	Mount Height= 6M : >102lux Mount Height= 8M : >57lux Mount Height= 10M : >37 lux Mount Height= 12M : >26 lux
	CRI	WW: Ra>60 PW:Ra>70
	Light Distribution Curve	Asymmetric (Bat Wing)
	Beam Angle	140 Degrees
	Light Decay	< 15% (20,000 hours)
ELECTRICAL	Input Voltage	AC85V-AC265V, AC277V+ (50Hz-60Hz)
	Working Voltage	36VDC
	TJ	60 °C ±10 %
	Lamp Efficiency	>88%
	Power Factor	>0.95
	IP Grade	IP65
MECHANICAL	Dimensions	L76W32H7.5cm(112W)
	Net Weight	10.5KG±5 %(112W)/7.5KG±5 %(56W) 13.5KG±5 %(168W)
	Material	Aluminum Alloy
	Working Environment	Temp: -40°C ~ 55°C Humid:10%-90%
	Dimension of pipe for installation	Φ62mm
