Kemet Smd Tantalum Capacitor

Specifications

kemet smd tantalum capacitor
Feature:high frequency and high voltage
SMD chip capacitor
Lead free/RoHS
Long operating life

kemet smd tantalum capacitor T491B476K010AT  tantalum capacitor





Specification:



Capacitor, tantalum, 47 uF, 3528, +/-10% Tol, 10V@85C





Dimensional Data (mm)
ID	Dimension	Tolerance
L:	3.5	+/-0.2
W:	2.8	+/-0.2
H:	1.9	+/-0.2
F:	2.2	+/-0.1
S:	0.8	+/-0.3
B:	0.4	+/-0.15
X:	0.1	+/-0.1
P:	0.5	REF
R:	1	REF
T:	0.13	REF
A:	2.1	MIN
G:	1.8	REF
E:	2.2	REF







Specifications
Manufacturer:	KEMET
Construction:	Standard Chip-MnO2
Capacitance:	47 uF
Voltage DC @ 85C:	10V
Voltage DC @ 105C:	8.5V
Voltage DC @ 125C:	7V
Tolerance:	+/-10%
Application:	General Purpose
Temperature Range:	-55/+125C
Body Type:	Molded Chip
ESR:	1 Ohm
Footprint:	3528
Termination:	Tin
RoHS:	Yes
Leakage Current:	4.7 uA
Dissipation Factor:	8%
Ripple @ 25C:	0.292 A
Ripple @ 85C:	0.2628 A
Ripple @ 105C:	0.1898 A
Ripple @ 125C:	0.1168 A
Package Kind:	T&R
Package Size:	7in
Package Quantity:	2000



 Picture:

















Customer's comment:

1.Impressed with the highest quality and best service

2.Reliable partner

3.Doing business with pleasure



Corporate Vision:

1.Best service

2.Good quality

3.Most favorable price

4.Sufficient supply



Shipping:

1. The items normally will be shipped out within 3 working days after the payment confirmed.

2. It will be shipped by DHL/FedEx /TNT/ UPS /EMS or other special way. Please contact with us and chose the best one.

You should pay attention to this:

3. Any accidents and delays or other issues caused by forwarder, please forgive that we can not take responsibility.

4. You should have to pay for all fees of shipping.



Refund & Replacement:

1. One month for return policy from the arrival date.

2. Please simply return to us for replacement or refund, when you find the unperfected quality items or they don’t work well.

3. If the items are defective please notify us within 3 days after arrival.

4. Any items must be returned in their original condition to get a refund or replacement.



Contact information:

Tel : 86-411- 82556766

 Fax: 86-411-82556988



 Other Policies:

1. About MOQ which depends on your order.

2. About warranty we give one month for refund or replacement.

3. About sample which needs your charge.

4. About inventory which changes everyday and depends on your order.

5. About order process: We will send you a PI (term of shipping, aggregate amount and so on) after receive you parts list.



We also take OEM,ODM orders as your design, if you have any question, feel free to contact us.
