Home > Products > HOT SALE -STOCK ITEMS > MURATA Choke Coil Inductor LQW18AN51NG00D
MURATA Choke Coil Inductor LQW18AN51NG00D
- Dalian
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Japan | Brand Name | MURATA | |
| Model Number | LQW18AN51NG00D |
Product Description
Specifications
MURATA choke coil inductor LQW18AN51NG00Ddimention 1.6x0.8x0.8mm
Inductance 51nH
Inductance test frequency 100MHz
MURATA choke coil inductor LQW18AN51NG00D
| Shape | ||
| L size | 1.6 ±0.2mm | |
| W size | 0.8 ±0.2mm | |
| T size | 0.8 ±0.2mm | |
| Size code mm (inch) | 1608 (0603) | |
| Specifications | ||
| Inductance | 51nH ±2% | |
| Inductance test frequency | 100MHz | |
| Rated current (Itemp) (Based on Temperature rise) | 370mA | |
| Max. of DC resistance | 0.33Ω | |
| Q (min.) | 38 | |
| Q test frequency | 200MHz | |
| Self resonance frequency (min.) | 2500MHz | |
| Operating temperature range (Self-temperature rise is not included) | -55~125°C | |
| References | ||
| Packaging | Specifications | Minimum quantity |
| code | ||
| D | φ180mm Paper taping | 4000 |
| J | φ330mm Paper taping | 10000 |
| B | Packing in bulk | 500 |
| Mass (Typ.) | ||
| 1 piece | 0.003g | |
MURATA inductor:
Corporate Vision:
1.Best service
2.Good quality
3.Competitive price
4.Sufficient supply
Shipping:
1. The items normally will be shipped out within 3 working days after the payment confirmed.
2. It will be shipped by DHL/FedEx /TNT/ UPS /EMS or other special way. Please contact with us and chose the best one.
You should pay attention to this:
3. Any accidents and delays or other issues caused by forwarder, please forgive that we can not take responsibility.
4. Your payment for the shipping cost will be highly appreciated.
Refund & Replacement:
1. One month for return policy from the arrival date.
2. Please simply return to us for replacement or refund, when you find the unperfected quality items or they don’t work well.
3. If the items are defective please notify us within 3 days after arrival.
4. Any items must be returned in their original condition to get a refund or replacement.
Contact information:
Tel : 86-411- 82556766
Fax: 86-411-82556988
Other Policies:
1. About MOQ which depends on your order.
2. About warranty we give one month for refund or replacement.
3. About sample which needs your charge.
4. About inventory which changes everyday and depends on your order.
5. About order process: We will send you a PI (term of shipping, aggregate amount and so on) after receive you parts list.
We also take OEM,ODM orders as your design, if you have any question, feel free to contact us.
