Multi Jet Dry Type Water Meter LXSC-15G-20G
US$ 2 - 50
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Aimei
Model Number:
LXSC-15G-20G
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LXSG-15E-1 Multi-jet Dry Type Water MeterUS$ 2 - 50MOQ: 1000 Pieces -
Multi Jet Wet Type Water MeterLXS-15E-50EUS$ 2 - 70MOQ: 1000 Pieces
-
Multi Jet Wet Type Hot Water Meter LXSR-15E-50EUS$ 2 - 70MOQ: 1000 Pieces
-
Volumetrice Rotary Piston Water Meter LXH-15A-40AUS$ 2 - 180MOQ: 1000 Pieces
-
LXL-80E-200EUS$ 5 - 200MOQ: 50 Pieces
Place of Origin
Zhejiang, China
Brand Name
Aimei
Model Number
LXSC-15G-20G
Specifications
Measuring the volume of potable water which consumed in houshold or a resident unit.Easy reading,good antifreezing property.APPLICATION:
This range of water meter is used to measure the total quantity of potable water which consumed in houshold or a resident unit, passing through the pipeline.
FEATURES:
This is a dry-type water meter.Its counting and measuring devices are driven by magnetic coupling. It is characterized by easy reading,good antifreezing property and ability to permanently keep the reading clear.
WORKING CONDITION:
COMPLIANCE WITH STANDARD: ISO 4064 (GB/T778-1996)
INDICATING ERROR:
At low zone is±5% from minimum flow rate(qmin)to transitional flow rate(qt)exclusive boundary
At high zone is±2% from transitional flow rate(qt) to overload flow rate(qs)
This range of water meter is used to measure the total quantity of potable water which consumed in houshold or a resident unit, passing through the pipeline.
FEATURES:
This is a dry-type water meter.Its counting and measuring devices are driven by magnetic coupling. It is characterized by easy reading,good antifreezing property and ability to permanently keep the reading clear.
WORKING CONDITION:
Water temperature: ≤40 for cold water meter
≤90 for hot water meter
Water pressure: ≤1MPa or 1.6MPa optional
(10bar or 16bar optional)
COMPLIANCE WITH STANDARD: ISO 4064 (GB/T778-1996)
INDICATING ERROR:
At low zone is±5% from minimum flow rate(qmin)to transitional flow rate(qt)exclusive boundary
At high zone is±2% from transitional flow rate(qt) to overload flow rate(qs)
ACCESSORIES
Each water meter has one set couplings optional: 2pcs tube, 2pcs nut and 2pcs gasket.
MAIN TECHNICAL DATA
Type |
Size (mm) |
Class |
Qn Max. Flow |
Qp Nominal Flow |
Qn Transitional Flow |
Qmin Min. Flow |
Min. Reading |
Max. Reading |
M3/h |
L/h |
M3 |
||||||
LXSC-15G |
15 |
A |
3 |
1.5 |
150 |
60 |
0.0001 |
99999 |
B |
120 |
30 |
||||||
LXSC-20G |
20 |
A |
5 |
2.5 |
250 |
100 |
0.0001 |
99999 |
B |
200 |
50 |
||||||
Type |
Size |
Length |
Width |
Height |
Connecting Thread D |
Weight (kg) |
mm | ||||||
LXSC-15G |
15 |
165/190 |
99 |
104 |
G 3/4B |
1.4/1.6 |
LXSC-20G |
20 |
190/195 |
99 |
106 |
G 1B |
1.7/1.8 |
