BELT CONVEYOR IDLER ROLLER FOR MINING

BELT CONVEYOR IDLER ROLLER FOR MINING thumbnail-1
BELT CONVEYOR IDLER ROLLER FOR MINING photo-1
US$ 6 - 50 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Condition:
New
Type:
Gravity Conveyor
Material:
Other, Carbon steel
Contact Supplier Request Quote Chat Now
Khodiyar Industrial Corporation
Payment & Shipping
Payment Methods:
Port of Shipment:
JNPT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Gravity Conveyor
Material Other, Carbon steel
Material Feature Heat Resistant
Structure Belt Conveyor
Place of Origin Gujarat, India
Brand Name KIC
Model Number KIC-CI-600-89
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

Details of conveyor roller :



Diameter:  50mm-219mm.



Length:  190-3400mm.



Tube:  customized Q235 welded steel tube or seamless tube



Shaft:   bright drawn steel to required bearing tolerance



Seals:  grease retaining inner seal with multi-layer labyrinth and retention cap with outboard rubbing flinger seal



Finish:  painting/rubber/galvanized



Welding: mixed gas shielded arc welding end



Painting: ordinary painting, hot galvanized painting, electric static spraying painting



Bearing:  single & double row deep groove ball bearing 2RZ & 2Z with C3 clearance



Shaft End: both ends of tube are simultaneously machined and chamfered



Lubrication: grease is lithium soap type grease with rust inhibitors

BELT CONVEYOR IDLER ROLLER FOR MINING

Advantages of conveyor roller/idler:
(1)Easy installation and nice flexibility;

(2)Low friction coefficient;
(3)Dust- and water-proof;
(4)Fine welding technique ensure roller with low vibration and noise;
(5)Electrostatic spraying technic makes the roller more durable and good-looking;
(6)Strict inspection standard ensures our high quality product.
Summary of Idler Size:



Standard Diameter
Length scope(mm)
Bearings Type(Min-Max)
Idler’s Shell Wall Thinkness
mm
Inch
63.5
21/2
150-3500
204
3.0mm-3.75mm
76
3
150-3500
204 205
3.0mm-4.0mm
89
31/3
150-3500
204 205
3.0mm-4.0mm
102
4
150-3500
204 205 305
3.5mm-4.0mm
108
41/4
150-3500
204 205 305 306
3.5mm-4.0mm
114
41/2
150-3500
204 205 305 306
3.5mm-4.5mm
127
5
150-3500
204 205 305 306
3.5mm-4.5mm
133
51/4
150-3500
204 206 207 305 306
3.5mm-4.5mm
140
51/2
150-3500
204 206 207 305 306
3.5mm-4.5mm
152
6
150-3500
204 206 207 305 306 307 308
4.0mm-4.5mm
159
61/4
150-3500
204 206 207 305 306 307 308
4.0mm-4.5mm
165
61/2
150-3500
207 305 306 307 308
4.5mm-6.0mm
177.8
7
150-3500
207 306 307 308 309
4.5mm-6.0mm
190.7
71/2
150-3500
207 306 307 308 309
4.5mm-6.0mm
194
75/8
150-3500
207 307 308 309 310
4.5mm-6.0mm
219
85/8
150-3500
308 309 310
4.5mm-6.0mm




Conveyor roller/idler are used in areas such as coal mining industry, cement industry, power plant and port etc.
We provide OEM service based on the design drawing or the sample. We can also provide any other customized belt conveyor idler rollers on the base of your drawings or
original samples.

Standard:GB,ISO,DIN,CEMA,JIS
BELT CONVEYOR IDLER ROLLER FOR MININGBELT CONVEYOR IDLER ROLLER FOR MININGBELT CONVEYOR IDLER ROLLER FOR MINING
