Help CenterWater Pump Pressure Switch
US$ 48 - 68
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KAIDI
Model Number:
KDMC2020
Payment & Shipping
Payment Methods:
Port of Shipment:
China any port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Pressure Switch Oil PressureUS$ 36 - 39MOQ: 1 Piece -
Mini Pressure TransmitterUS$ 75 - 99MOQ: 1 Piece
-
Mini Piezoresistive Pressure TransmitterUS$ 75 - 99MOQ: 1 Piece
-
Piezoresistive Pressure TransmitterUS$ 75 - 99MOQ: 1 Piece
-
Smart Water Level Sensor Pressure TransmitterUS$ 75 - 99MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
KAIDI
Model Number
KDMC2020
Water pressure switch oil pressure
Specifications:
Measuring ranges: see table below
Output: NO+NC and silver plated contact
≤DC42V, 3A
≤DC125V, 8.5A
≤AC250V, 4.5A
Medium temperature: -45~120 ° C
Protection rating IP33
Interface thread: 1/4 "SAE
Connection: Terminal wiring
Material: wetted parts: brass nickel plated, Case: NBR
35
Model |
Range(bar) |
Differential (bar) |
Factory default(bar) |
Max Press.(bar) |
|||
Min |
Max |
Min |
Max |
OFF |
ON |
||
MC2020-502 |
-0.7 |
2 |
0.2 |
1.0 |
1.5 |
1 |
16.5 |
MC2020-503 |
-0.7 |
3 |
0.2 |
1.5 |
2 |
1 |
16.5 |
MC2020-506 |
-0.7 |
6 |
0.6 |
4 |
3 |
2 |
16.5 |
MC2020-506M |
-0.7 |
6 |
Reset pressure≤1 |
3 |
Manual reset |
16.5 |
|
MC2020-110 |
1 |
10 |
1 |
3 |
6 |
5 |
16.5 |
MC2020-516 |
5 |
16 |
1 |
4 |
10 |
8 |
35 |
MC2020-520 |
5 |
24 |
2 |
5 |
16 |
13 |
35 |
MC2020-530D |
5 |
30 |
5 |
10 |
20 |
15 |
35 |
MC2020-530 |
8 |
30 |
Fixed 3-5 |
20 |
15-17 |
35 |
|
MC2020-530M |
8 |
30 |
Reset pressure≤4 |
20 |
Manual reset |
||
