Home > Industrial Equipment & Components > Valve > Ball Valve > KDQII Electric Rotary Valve Actuator

KDQII Electric Rotary Valve Actuator

Name: KDQII Electric Rotary Valve Actuator
Brand: KAIDI
SKU: 122951319
Availability: InStock

KDQII Electric Rotary Valve Actuator thumbnail-1

KDQII Electric Rotary Valve Actuator photo-1

US$ 1,000 - 8,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

KAIDI

Model Number:

KDQII

Contact Supplier Request Quote Chat Now

Guangdong Kaidi Energy Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

CHINA

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name KAIDI

Model Number KDQII

Specifications

1. Torque : 50 NM ~ 3000 NM
2. Operating time : 10 sec ~ 135 Sec .
3. Weatherproof: IP 65
4. Output: 4-20mA

KDQII/KDMQII range multi-turn intelligent actuator has been widely used in power plant, metallurgy, petroleum, chemistry industry, water conservancy, machine, light industry, fire protection, and environment protection department and so on. The all functions can be rapidly set up by the hand-held, non-intrusively, infra-red setting tool without removing electrical covers (even in wet or hazardous situations).

Specification:

Power supply	380VAC/50Hz/3ph	Please statement for other power supply in order form
Input signals	DC4~20mA. DC24V. AC220V. Fildbus
Output signals	DC4~20mA.		6 status contacts can be configured at the local. 1 contacts for indicating remote or local. 1 contacts for indicating faults.
Contacts capability	250VAC/5A or 30VDC/5A
CPT load	≤750Ω
Output torque	see table 1
Output speed	see table 1
Safety grade	Watertight enclosure: IP68
Explosive proof	Exd II CT4
Environment temperature	-10°C~+70°C or optional: -30°C~+70°C
Lubrication	Senior lubricant
Install	Install flange conforms to the ISO5210:2001(GB/T12222-2005)(see table 3),the other configuration flange can be assembled yet according to user’s demand.
Wiring holes	One M40x1.5 and Two M25x1.5 spiral holes,cable diameter is 22~32mm , and water proof type adopts clamp tie-in; Explosion proof type adopts explosion proof tie-in or screw thread pipe.
