Kaidi KDQII Valve Electric Actuator

Name: Kaidi KDQII Valve Electric Actuator
Brand: KAIDI
SKU: 122951313
Availability: InStock

US$ 2,000 - 5,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

KAIDI

Model Number:

NDQII

Guangdong Kaidi Energy Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KAIDI

Model Number NDQII

Specifications

1. multi-turn electric actuator
2. up to 60 starts per hour
3. Safety grade: IP68
4. Explosive proof: Exd II CT4

Power supply	380VAC/50Hz/3ph, 220VAC/50Hz/1ph	Please statement for other power supply in order form
Input signals	DC4~20mA. DC24V. AC220V. Fildbus
Output signals	DC4~20mA.	6 status contacts can be configured at the local. 1 contacts for indicating remote or local. 1 contacts for indicating faults.
Contacts capability	250VAC/5A or 30VDC/5A
CPT load	≤750Ω
Output torque	see table 1
Output speed	see table 1
Safety grade	Watertight enclosure: IP68
Explosive proof	Exd II CT4
Environment temperature	-10°C~+70°C or optional: -30°C~+70°C
Lubrication	Senior lubricant
Install	Install flange conforms to the ISO5210:2001(GB/T12222-2005)(see table 3),the other configuration flange can be assembled yet according to user ‘s demand.
Wiring holes	One M40x1.5 and Two M25x1.5 spiral holes,cable diameter is 22~32mm , and water proof type adopts clamp tie-in; explosion proof type adopts explosion proof tie-in or screw thread pipe.
