300w Fiber Laser Cutting Machine





1. The machine uses moving gantry structure, imported high-precision screw rod linear guide, smooth transmission, high precision.
2. Bed and moving beams are made of welded structures for roughing after annealing, and then the vibration aging treatment can completely eliminate stress welding and machining, good rigidity, high precision, can be maintained long-term use is not deformed.
4. X, Y, Z axis servo motors are imported from Japan, high-precision, high-speed, high-torque, high inertia, stable and durable performance. Ensure the machine's speed and acceleration.
5. Based on the Windows operating system CYPCUT fiber laser cutting machine for CNC system integrates many laser cutting control special function modules, powerful, good man-machine interface, easy operation.
6. Expert Edition FAST CAM nesting software, CNC cutting machine to achieve "full-time cut, high efficient cutting and nesting rate cut," the core technology is an effective material savings, improve cutting efficiency of the fundamental guarantee.
7. Germany imported high-precision electronic control proportional valve, precise control of the cutting assist gas pressure, in order to achieve the best cutting results.





No. NL-FC5050-250W NL-FC1325-500W
1 Work table size 500 500mm 1300X2500mm
2 X axis stroke 520mm/1320mm
3 Y axis stroke 520mm/2520mm
4 Z axis stroke 50mm
5 X/Y axis setting accuracy 0.02mm/m
6 X/Y axis repeat accuracy +0.02mm
7 Max work speed 2~10m/min
8 Max.accelerated speed 0.5G
9 Machine N.W 500Kg
10 CNC system HI800
11 Max loading weight of work table 30kg
12 Power phase 2phase
13 Power Supply 220V-50~60Hz
14 Protecting level of general power IP54







one year guarantee for a whole machine(excluded glass laser tube)'prompt response'24hours phone or online service'engineer oversea service possible
