SBW THREE PHASE 5000va voltage stabilizers
This product is designeg and developed with the international advanced compensation technology .It can keep the output voltage in steady state automatically when the network voltage fluctuated or the load current varied, which can ensure the consumer run smoothly. It has the advantage of large capacity, high efficiency, no waveform distortion,simple operation and maintenance,reliabie running,full-capacity output under tower input voltage if compared with other voltage stabilizer. It is provided with over-voltage,over-current,phase sequence and so on protection function
Scope of Application
It is suitable for electric supply in small-sized plant,workshop and department inmiddle,large-
sizde mining enterprise,it can be widely used in the precision machine tool,precision instrument,
test device,elevator,imported electromechanical device,production flow-line in the mining ent-
erprise,oil field,railway,building site,school,hospital,hotel,scientificresearch department
and so on, it is also suitable for the user in the LV electric network end with low power voltage and
big wave range.
SPECIFICATION & PERFORMANCE
Model |
SBW20KVA-1000KVA(Triple) |
DBW10KVA-100KVA(single) |
Input voltage range |
304V-456V |
176V-264V |
Output voltage |
380V±(1-5%)settable |
220V±(1-5%)settable |
Regulation accuracy |
±(1-5%)settable |
|
Insulation resistance |
≥2M Ω |
|
Withstand voltage |
2000V1min no disruption or flashover phenomenon |
1500V1min no disruption or flashover phenomenon |
Frequency |
50HZ/60HZ |
|
Response time |
≤1.5S(when output voltage has changed 10%) |
|
Efficiency |
≥98% |
|
Waveform aberration |
<1% |
|
Ambient temp |
-5°C-+40°C |
|
Relative humidity |
<90% |
|
Model |
Measurement (cm) |
Output power(KVA) |
Weight (KG) |
SBW-50K |
80×62×135 |
50 |
250 |
SBW-60K |
80×62×135 |
60 |
350 |
SBW-100K |
85×62×150 |
100 |
420 |
SBW-150K |
100×72×170 |
150 |
550 |
SBW-180K |
100×72×170 |
180 |
570 |
SBW-200K |
100×72×200 |
200 |
630 |
SBW-225K |
110×80×180 |
225 |
660 |
SBW-250K |
110×80×200 |
250 |
700 |
SBW-300K |
110×80×210 |
300 |
740 |
SBW-320K |
110×80×210 |
320 |
760 |
SBW-400K |
100×80×210/2cabinet |
400 |
1100 |
SBW-500K |
100×80×210/2cabinet |
500 |
1500 |
SBW-600K |
100×80×210/2cabinet |
600 |
2200 |
SBW-800K |
85×100×220/3cabinet |
800 |
2800 |
SBW-1000K |
85×100×220/3cabinet |
1000 |
3500 |
SBW-1200K |
85×100×220/3cabinet |
1200 |
4100 |
SBW-1600K |
110×110×220/4cabinet |
1600 |
5560 |
SBW-2000K |
110×110×220/4cabinet |
2000 |
7100 |
