E Series Chambers Electric Oven

US$ 1 - 1.01 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SAM

Model Number:

CS101-1EBN

Shenzhen SAM Electronic Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen/hongkong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SAM

Model Number CS101-1EBN

Power Electronic

Usage Auto Testing Machine

Sta ndards implemented and met

Model		CS101-1EBN	CS101-2EBN		CS101-3EBN
Performance
Circulation method	Forced air circulation
Temp range	R.T+10°C-300°C
Temp constancy	±0.5°C
Temp homogeneity	±2.5%
Heat up time	Approx *70min
Components
Interior material		Stainless steel SUS 304(EBN series Cold rolled plate with baked coating finish (EN series)
Exterior material		Electrostatic spraying of epoxy powder on cold-rolled steel sheet
Observation window		Hollow high temperature resistant toughened glass
Heat insulating material		Class wool
Sealing of door		Environment -friendly silicone rubber strip
Exhaust port		45mm I.D *1 the back side
Circulating fan		Centrifugal blower
Motor		Condenser type
Heater		Iron-chrome wire heater
Controller
Temp control method		PID control by microprocessor
Temp setting method		Digital setting by up and down key
Temp display method		Digital display by LED
Operation function		Fixed temperature operation
Heater circuit control		Triac zero-cross control
Safe device
Independent overtemp .prevention ,breaker with overcurrent protection
Standard
Internal dimensions		400450400(mm)	500550500	600650600
External dimensions		575610905"(mm)	6757101025	7758101175
Internal capacity (L)		72	137.5	234
Power supply		AV220V 50HZ
Power (KW)		Approx*1.5	Approx*2.5	Approx*3
Accessories
Shelf plate ,2 sets/product description
Optional accessories
Program temp control /additional shelf plate /cable hole 50mm/ external communication terminal (RS485)etc
