WGD50800G Programmble High/low Temperature Test Chamber

WGD50800G Programmble High/low Temperature Test Chamber thumbnail-1
WGD50800G Programmble High/low Temperature Test Chamber photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SAM
Model Number:
WGD50800G
Contact Supplier Request Quote Chat Now
Shenzhen SAM Electronic Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SAM
Model Number WGD50800G
Power Electronic
Usage Other

Specifications

Programmable high-low temperature test chamber

Balanced temperature & humidity control system(BTHC),thod control SSR .The heating and  moisture system content is equal to the heat and moisture loss, therefore, can stability use long-term .Adopt cooling cold quantity control output mode, saving energy above 20% compare with the simliar products .



Specification



Performance

System

Balanced temperature control system

Circulation method

 Forced air circulation

Temperature range

-50~150°C

Temp.fluctuation

≤1°C

Temp. gradient

≤2°C    (-50~+100°C)

Temp. variation

 ±2.0°C

Increasing temp. time

-50→+150°C


 Approx. 60min

Reducing temp. time

+20→-40°C


 Approx. 40min

Components

Interior material

SUS304  Stainless steel SUS304

Exterior material

Cold rolled steel plate with melamine resin baking finish

Heat insulating material

Rigid polyurethane foam+glass wool

Heater

Ni-chrome strip wire heater

Circulating fan

Multi-wing centrifugal blow fan

Motor

Condenser type, 90W 4PCS

Sensor

PT100Ω

Viewing window

Glass incorporating heat generator

Cable hole

  Inside diameter Φ50

Caster wheel

Locking Caster wheel

Controller

Temp. controller

PID control by microprocessor

Temp. setting method

Digital setting with the UP/DOWN key

Temp. display method

Digital display by LED

Min. division

1 Min.

Operation function

Fixed temperature operation, Program temperature operation

Programs

4 Patten total  40steps

cycles

1~9999

Operation Panel

Power switch,  Independent overtemp. prevention, Temperature controller

Refrigeration system

Refrigerating mode

Compressor cascade refrigeration(Air-cooled condenser)

Refrigerator

Hermetically sealed rotary compressor

Refrigerant

Non-chlorofluorocarbon Coolant R404A+R23

Condenser

Finned heat exchanger

Evaporator

inned tube Evaporator

Safe Device

Independence overtemp. protection/over current breaker/ Refrigerator overload relay,refrigerator overpressure and overheat  protection/fuse-wire

Standard

Internal dimensions

750×1400×1000mm (D×W×H)

External dimensions

About 1200×1810×1680mm (D×W×H)(not including motor height 180mm)

Internal capacity

800liters

Power source

3 4w380V±10%, 50/60Hz     MAX9KW

Accessories

Stainless steel shelves plate, 2pcs/ cable hole lid(Φ50),1pcs/chamber lamp,1pcs/ Product description, 1set/Communication interface(232 or 485)

Optional Accesseies

Additional shelf plate
