Help CenterE Series Electric Dryig Oven
Related Products
Features
1.Microcomputer PID control is used with self-turing PID function, make sure equipment
can reach the best accuracy of temperature controil at any working state ,
2.Enter parameterse manually by pressing up and down key , the setting is simple and convenient , in the meantime,
the set temperature and measured temperature are displayed.
3.Convenient temperature compensation function can avoid the error between displayed temperature and measured temperature,
4.The products have function of timing constat temperature when the measured temperature has reached the set temperature.
5. With independent overtemperature protection device, reliability and safety of products are improved .
6. Side heating is adopted , which will not damage the heater even dripping samples that are dried , and it is easy to clean the oven body.
7. Equipped with caster wheel convenient for the movement of products.
Application
Electronics, Electronical engineering , instruments , material ,semiconductor manufacturing enerprise do drying ,
baking , thermakl insulations and heat treatment test on non-inflammable and non-explosive goods .
School , biological pharmaceutical , food , cosmetics , tobacco , microorganism , chemical industry units do drying m baking and
sterilization test on sample research,
Especially suitable for drying and ageing of products such ad LED,LCD.quartz crystal , optical fiber, capacitor , resistor , inductor during production process.
Standards implemented and met
Model |
CS101-1EBN |
CS101-2EBN |
CS101-3EBN |
||
Performance | |||||
Circulation method |
Forced air circulation |
||||
Temp range |
R.T+10°C-300°C |
||||
Temp constancy |
±0.5°C |
||||
Temp homogeneity |
±2.5% |
||||
Heat up time |
Approx *70min |
||||
Components | |||||
Interior material |
Stainless steel SUS 304(EBN series Cold rolled plate with baked coating finish (EN series) |
||||
Exterior material |
Electrostatic spraying of epoxy powder on cold-rolled steel sheet |
||||
Observation window |
Hollow high temperature resistant toughened glass |
||||
Heat insulating material |
Class wool |
||||
Sealing of door |
Environment -friendly silicone rubber strip |
||||
Exhaust port |
45mm I.D *1 the back side |
||||
Circulating fan |
Centrifugal blower |
||||
Motor |
Condenser type |
||||
Heater |
Iron-chrome wire heater |
||||
Controller | |||||
Temp control method |
PID control by microprocessor |
||||
Temp setting method |
Digital setting by up and down key |
||||
Temp display method |
Digital display by LED |
||||
Operation function |
Fixed temperature operation |
||||
Heater circuit control |
Triac zero-cross control |
||||
Safe device | |||||
Independent overtemp .prevention ,breaker with overcurrent protection | |||||
Standard | |||||
Internal dimensions |
400*450*400(mm) |
500*550*500 |
600*650*600 |
||
External dimensions |
575*610*905"(mm) |
675*710*1025 |
775*810*1175 |
||
Internal capacity (L) |
72 |
137.5 |
234 |
||
Power supply |
AV220V 50HZ |
||||
Power (KW) |
Approx*1.5 |
Approx*2.5 |
Approx*3 |
||
Accessories | |||||
Shelf plate ,2 sets/product description | |||||
Optional accessories | |||||
Program temp control /additional shelf plate /cable hole 50mm/ external communication terminal (RS485)etc | |||||
