Truck Crane (brand New 30t Truck Crane,6x4 Truck Crane, QY30 Truck Crane)

Name: Truck Crane (brand New 30t Truck Crane,6x4 Truck Crane, QY30 Truck Crane)
Brand: Zoomlion
SKU: 122879567
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Rated Loading Capacity:

30000

Rated Lifting Moment:

1132 kN.m

Max. Lifting Load:

30000

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Rated Loading Capacity 30000

Rated Lifting Moment 1132 kN.m

Max. Lifting Load 30000

Max. Lifting Height 48.5

Place of Origin Hunan, China

Brand Name Zoomlion

Model Number QY30V531

Specifications

Capacity: 30 tons(brand new truck crane)
Drive style: 6x4
Emission: Euro III
Boom length: 10.6~40m
Jib length: 8m

Truck Crane (brand new 30t Truck Crane,6x4 truck crane, QY30 truck crane)

Capacity: 30tons(brand new truck crane)

Drive style: 6x4

Boom length: 10.6~40m

Jib length: 8m

Emission: Euro III

Main Technical Specification

Item				Value	Remarks
Working performance specification	Max. rated total lifting capacity kg			30000
	Max. load moment of basic boom kN.m			1132
	Max. load moment with max. main boom length kN.m			588
	Max. lifting height of basic boom m			11.1
	Max. lifting height of main boom m			40.5	Deformation of boom is not taken into consideration.
	Max. lifting height of fly jib m			49
Working speed	Max. speed of single rope on main winch m/min			120	The 4th layer of drum
	Max. speed of single rope on auxiliary winch m/min			77	The 2nd layer of drum
	Derricking time of boom s			45
	Telescopic time of boom s			85
	Slewing speed r/min			02.2
Traveling specification	Max. traveling speed km/h			78
	Max. gradeability %			37
	Min. turning circle diameter m			22
	Min. ground clearance mm			220
	Limits for exhaust pollutants and smoke			Comply with related standards	GB3847-2005 GB17691-2005 (Stage)
	Oil consumption per hundred kilometers L			45
Mass specification	Deadweight of crane in traveling condition kg			31830
	Complete vehicle kerb mass kg			31700
	Front axle load kg			6990
	Rear axle load kg			24840
Dimension specification	Overall dimensions (L×W×H) mm			13000×2500×3400
	Base on outriggers m			5.36
	Distance between outriggers m			6.1
	Main boom length m			10.640.0
	Main boom angle °			-280
	Fly jib length m			8
	Offset angle of fly jib °			0 , 30
Chassis	Model			ZLJ5323	Feature NoZLJ5323V3.2 ZLJ5323V3.3T
	Class			II
	Engine	Model		WP10.270	QSC 260
		Rated power kW/r/min		199/2200	194/2200
		Max. output torque N.m/r/min		1100/13001600	1180/1500
	Manufacturer		Changsha Zoomlion Heavy Industry Science & Technology Development Co., Ltd.
