QY25K-II XCMG Hydraulic Crane for Sale

Name: QY25K-II XCMG Hydraulic Crane for Sale
Brand: XCMG
SKU: 122879449
Availability: InStock

US$ 50,000 - 500,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Application:

building

Rated Loading Capacity:

25 tons

Shanghai Longji Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application building

Rated Loading Capacity 25 tons

Rated Lifting Moment 1010 KN/m

Max. Lifting Load 25T

Max. Lifting Height 42.15m

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number QY25K-II

Certification SGS,CE

Warranty 1year or 1200working hours

After-sales Service Provided Engineers available to service machinery overseas

Dimension	Unit	QY25K-II
Overall length	mm	12650
Overall width	mm	2500
Overall height	mm	3380
Weight
Total weight in travel	kg	29400
Front axle load	kg	6200
Rear axle load	kg	23200
Power
Engine model		SC8DK280Q3 / WD615.329(domestic III)
Engine rated power	kW/(r/min)	206/2200 213/2200
Engine rated torque	N.m/(r/min)	1112/1400 1160/1400
Travel
Max. travel speed	km/h	75
Min. turning diameter	m	21.5
Min. ground clearance	mm	275
Approach angle	°	16
Departure angle	°	13
Max. grade ability	%	30
Fuel consumption for 100km	L	≈37
Main performance
Max. rated total lifting capacity	t	25
Min. rated working radius	mm	3000
Turning radius at turntable tail	m	3.065
Max. lifting torque	kN.m	1010
Base boom	m	10.7
Fully extended boom	m	34.19
Fully extended boom+jib	m	42.15
Longitudinal outrigger span	m	5.14
Lateral outrigger span	m	6
Working speed
Boom luffing time	s	75
Boom full extension time	s	100
Max. swing speed	r/min	≥2.5
Max. speed of main winch (single rope)	m/min	≥120
Max. speed of aux. winch (single rope)	m/min	≥120
