Home > Instruments & Meters > Meter for Electricity > Energy Meter & Power Meter > Single-phase Elecrical Watt-hour Meter

Single-phase Elecrical Watt-hour Meter

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

OEM

Model Number:

DDS238

Contact Supplier Request Quote Chat Now

Yueqing Haohua Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI OR NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name OEM

Model Number DDS238

Phase Single Phase

Output Voltage 120V,220V,230V,240V

Application
     DDS238 single phase electrical watt-hour meter adopt a large scale of integrated circuits and SMT technology, whole screen and anti-jamming structure, its technical performance are completely conform to national standard GB/T 17215-2002 and international standard IEC62053.The meter has the following features:
  (1)High reliability, low power loss, high accuracy, wide load capacity.
  (2)Can accurately measure active energy power from positive direction and negative direction, and accumulative total in the same direction, and has function of anti-stealing electricity.
  (3) adopt photo-electricity coupling no power pulse output, and indication using electricity by LED, and can realize collecting reading meter so as to control using electricity and management. It is used for measuring active energy power loss in frequency 50 Hz or 60 Hz single phase AC electricity net and which is installed in meter box indoors or outdoors.

Technical parameters

Type	Accuracy (class)	Rated Voltage(V)	Rated current(A)	Starting Current	Insulation Performance
DDS238	1	220-240V	1.5(6),2.5(10) 5(20),5(30) 5(40),5(60),10(40),10(60) 15(60),10(80) 20(80) ,20(100),30(100)	0.4%Ib	AC voltage 2KV for 1 minute impulse voltage 6kV
