Anchor Rope Capstan

Name: Anchor Rope Capstan
Brand: Xichang
SKU: 122867985
Availability: InStock

US$ 2,000 - 20,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Hubei, China

Brand Name:

Xichang

Model Number:

brand new

Wuhan Jiangnan Anchor Chain Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hubei, China

Brand Name Xichang

Model Number brand new

Part Other, Marine Hardware

We can supply various deck machinery:

Windlass/ Mooring Winch/ Capston

Cable chain: 12.5-114mm

Hositing force:10KN to 600KN

Mooring force:30KN to 300KN

Sepcail winches could reach 300KN pull load according to the usages.

Capstan

Name	Warping Load (KN)	Warping Speed (m/min)	Wire Dia. (mm)
5kN Electric (Hydraulic) Mooring Rope Capstan	5	≥18	Φ11
10kN Electric (Hydraulic) Mooring Rope Capstan	10	≥18	Φ11
15kN Electric (Hydraulic) Mooring Rope Capstan	15	≥18	Φ13
20kN Electric (Hydraulic) Mooring Rope Capstan	20	≥18	Φ15
30kN Electric (Hydraulic) Mooring Rope Capstan	30	≥18	Φ17.5
50kN Electric (Hydraulic) Mooring Rope Capstan	50	≥18	Φ20.5
70kN Electric (Hydraulic) Mooring Rope Capstan	70	≥15	Φ26
100kN Electric (Hydraulic) Mooring Rope Capstan	100	≥15	Φ28
120kN Electric (Hydraulic) Mooring Rope Capstan	120	≥15	Φ32.5
150kN Electric (Hydraulic) Mooring Rope Capstan	150	≥15	Φ36.5
