Impact PulverizerMin. Order: 1 Set
FOB Price: US $1-99999 / Set
Supply Ability: 50 Set/Sets per Year
Impact Pulverizer is suitable for grinding of Resins, Minerals, Clays, Limestone, Neeru, Dolomite, Coal, Bauxite, Barites, Gypsum, China Clay, Soap Stone, Calcite, Bentonite, Calcite bone, Carbon Black, Feldspar, Kaolin, Talc, Mica Chips, Asbestos, Leather chips, Basin, Gram Dal, etc.
The Pulverizer consists of a machined body bolted together inside which rotate forged steel hard faced balanced hammers mounted on a solid alloy steel shafting. The shaft rotates in self aligning ball bearings installed in C.I. housings provided with grease cups. Replaceable C.I. breakers plate is fitted on to the main body which acts as the stator and facilitates Pulverizing. The material is filled in a hopper and fed by means of a automatic rotary feeder gear driven from the main shaft. After Pulverizing the material is separated by a whizzer type classifier provided with adjustable mesh control to control fineness. A paddle type section is provided complete with pneumatically working cyclone, 49 nos mechanical shaking PP Bags with 3 HP motor dust collector and interconnecting piping.
