Specifications
Full automatic disk wood chipperSpiral chipper disc surface may be less than 200mm diameter cutting logs, wood and branch.
Full automatic disk wood chipper
Spiral chipper disc surface may be less than 200mm diameter cutting logs, wood and branches path material, applied to paper pulp factory, forest games, paper mills, wood chips and other plants. Mainly by the chipper host, couplings, chassis, motor, such as four-part composition, in which the host by the chipper knives plate, upper and lower casing, a material feed port and the mouth parts, etc.
main technical parameters
Machine Model |
600 |
800 |
|
Cutter diameter (mm) |
600 |
800 |
Cutterhead speed(r/min) |
970 |
740 |
Thickness mm Length mm chips |
15-35 2-3 |
15-35 3-7 |
Thickness mm Length mm chips |
Under oblique |
Under oblique |
I feed size mm |
150×140 |
250×250 |
Capacity t / h |
1-3 |
3-5 |
Motor Power kw |
15 |
30 |
Mm maximum diameter of the timber cutting |
200 |
250 |
A material way |
Oblique on the |
Oblique on the |
Kg whole weight |
1192 |
1680 |
Overall dimensions (L × W × H) |
2002×1175×1360 |
2008×1838×1492 |
Further information please don't hesitate to contact us!
