Automatic Dispenser Paper Making Machine , Toilet Paper Reels Slitter and Rewinder Machine
- 600 Unit / Units per Month
- Qingdao Shanghai
- T/T Credit Card
- Automatic Toilet Paper Machine , Paper Making Machine
- Dispenser Paper Making Machine , Jumbo Roll Slitting and Rewinding Machine
- Automatic Mother Jumbo Roll Dispenser Paper Making Machine , Slitting Rewinding Machine
- Full Automatic Toilet Rolls Making Machine , Paper Slitter Rewinder Machine
- Dispenser Paper Making Machine , Full Automatic Paper Machine
- Dispenser Paper Making Machine , Small Model Toilet Paper Making Machine
Product Details
Condition: | New | Type: | Slitting Rewinder | Computerized: | Yes |
Place of Origin: | Henan, China | Brand Name: | HengYuan slitter and rewinder machine | Model Number: | HY-1880 slitter and rewinder machine |
Voltage: | 380V, 3 phases | Power(W): | 4.5KW | Dimension(L*W*H): | 5800mm*2800mm*1750mm |
Weight: | 1200kg | Certification: | ISO9001 | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
slitter and rewinder machine is in full 20FT container, or wooden case, or as clients' special requirements.
Product Description
Automatic Dispenser Paper Making Machine, Toilet Paper Reels Slitter and Rewinder Machine 0086-13103882368
- Introduction of Slitter and Rewinder Machine
This kind of slitting rewinder is used to slit and rewind the bathroom tissue, non-woven materials. The single ply paper can be slit and rewinded into two, three or four ply paper with various widths, for the production of napkins, hankies, facials or sanitary napkins. The machine is featured of good performance, compact structure, and stable running, easy operation. The finished products has good winding profiles, which make it a good equipment for the paper mills and textile factories, and a high reputation from the customers. The machine can be equipped with double calendering rolls.
- Main Technical Data of Slitter and Rewinder Machine
Name of machine | slitter and rewinder machine | |||||
Model | HY-1575 | HY-1880 | ||||
Width of raw paper | 1800mm | 2200mm | ||||
Diameter of finished products | Φ90~300mm(adjustable) | |||||
Diameter of raw material | Φ1600mm(can be specified) | |||||
ID of raw material core | 76.2mm(can be specified) | |||||
Perforating pitch | 90-160mm | |||||
Capacity | 150-180m/min | |||||
Rewinding unit | Air shaft | |||||
Unwinding stand | 1-3 layers(customizable) | |||||
Pneumatic system | 3HP air compressor, min. Air pressure is 5kg/cm2 Pa(provided by customer) | |||||
Power | 4.5KW | |||||
Overall dimension | 5800mm*2800mm*1750mm | |||||
Weight | According to different models |
- Functions of Slitter and Rewinder Machine
1.Adopts air swelling shaft to furl roll(or to use pneumatic style to furl roll), the tension of furling roll can be adjusted.
2.Blank pressing system: using steel to steel blank pressing and independent cylinder, to make the paper non separation.
3. Three backstands, pneumatic jumbo roll loading, and pneumatically wide belt paper unwinding driving, and individual web tension control unit for each jumbo roll.
4. Trimming, gluing and sealing device can be customized as clients’ requests.
- Detailed Pictures of Slitter and Rewinder Machine
- Finished Products of Slitter and Rewinder Machine
- Detailed Pictures of Slitter and Rewinder Machine
Our factory covers an area of about 4,000 square meters, we own our dedicated workshop, warehouse for producing and storing. There are 4-5 engineers, 2-4 quality control personnels, and several managers.
We have customers from worldwide, such as Egypt, Nigeria, England, Uzbekistan, Afghanistan, Russia, Kazakhstan, Viet Nam, etc.
- After service
We will provide operation video and manual for assistant. If necessary, our engineer will go to your factory for guiding.
- Guarantee
The main body(not included the motor and wear parts) guarantee is one year. During the guarantee period, if the main body defective as the bad quality without any workers wrong operation, Xuchang Hengyuan Paper Machinery Co., Ltd. should replace the parts for free or prepare the goods for free. Beyond period, only manufacturing cost will be charged for spare parts.
- What is the net profit of toilet paper and napkin paper?
For toilet paper, it is about 20%. That is, the profit is about USD100-USD140 for per ton.
For napkin tissue, it is about 30%. That is, the profit is about USD350 for each ton.
- How can customers obtain the raw material?
The raw materials are mainly made from wood pulp, cane syrup, deinked waste paper.
You can purchase the raw material in your area. If you like, we can purchase raw material from our cooperated suppliers in China at low cost for you.
- How many bags can we get from 1 ton of raw pulp material?
If 100g for one roll of paper, 10 rolls in a bag, we can get about 900 bags from 1 ton of raw material.
- For our HY-1880 toilet paper rewinding machine, what is the plant area?
The overall dimension of our machine is 6m(length)*3m(width)*1.8m(height), to take the working table into account, the plant area is about 50m2. The height of door is 2m. (The warehouse is not included. )
- What is the investment for processing toilet paper?
About USD17,000. It includes the equipments(rewinding machine+slitting machine+sealing machine), workshop, raw material, etc.
Any more further information, please feel free to contact me.
Company Profile
Xuchang HengYuan Paper Machinery Co., Ltd. Is a professional manufacturer at producing paper machinery. It has been grown and developed for more than twenty years since it is established in 1990. Our main products are rewinding machine, paper napkin machine, slitter, handkerchief paper machine, tissue paper machine, removable tissue machine, etc.
The company always insist quality for survival, technology innovation for development, relying on excellent quality and good after-sale service, our products have been exported to home and abroad. The toilet paper rewinding machine and paper napkin machine make we are unique in the counterparts.
We have equipments with reliable quality, excellent performance, high efficiency and advanced function. Professional engineers are available for equipments installation, debugging and after-sale service. In order to satisfy your various needs. Our staff will continue efforts and improve the existing products as always. Quality first, integrity supremacy are always our concept. We will dedicated to service our general customer.
