Home > Products > Rubber equipment > Automatic tyre shredder machine / tire shredder
Automatic tyre shredder machine / tire shredder
- 50 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Other, Tire Machine, Whole tire shredder | Tire Machine Type: | Tire Recycling Machine |
Place of Origin: | Shandong, China | Brand Name: | QDHC | Model Number: | ZPS series |
Voltage: | 220V-440V | Power(W): | According to different machine | Dimension(L*W*H): | According to different machine |
Weight: | According to different machine | Certification: | CE/ISO | Warranty: | One year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Automatic tyre shredder machine / tire shredder
Structure and Principle
- The shredding chamber adopts folio compact structure for easy maintenance;
- The shredding blade edges are made of hard alloy after special hardness treatment, wear-proof. The blade edges are made replaceable without dismantling the machine, blades changing and repairing jobs are made easy and not costly any more. Heavy-duty, advanced technology and high output;
- The machine adopts low noise, steady and high torque planet-gear speed reducer, easy and safe operation;
- The rotary screener is of steel net structure which has large area for screening qualified size of tire chips to discharge quickly. Low consumption, high output and advanced technology.
Technical details:
Model | ZPS-800 | ZPS-1200 |
Production capacity | 0.8-2 Ton/hour | 1.5-3 T/h |
Size of feeding | ≤800 mm whole tyre | ≤1200 mm whole tyre |
Discharging particles | ≤50*50mm | ≤60*60mm |
Motor powder | 45 kw | 155 kw |
Discharging motor | 2.2 kw | 4 kw |
Cutter rotate speed | 16 r/min | 31 r/min |
Screener rotate speed | 6 r/min | 8 r/min |
Dimension (L*W*H) | 2.8*2.1*2.4 m | 5.2*2.5*3.8 m |
1.Pre-sale services:
Provide the consultation of the equipment. According to the clients’ special requirement, offering the reasonable plan helping to select the equipment.Welcome to visit our factory.
2.Services during the sales:
Inspect the machine before leaving the factory.Oversea install and debug the equipment. Train the first-line operator.
3.After sale services:
Provide technical exchanging and timely problem solving support.
" Quality comes first" is our principle to run the factory. "
Honesty and mutual benefits"is our basis to do business.
We are looking forward to cooperating and establishing long-term
business relationships with friends from all over the world.
Tel:0086-532-85191579
Fax:0086-532-85191579
Contact Us
- Qingdao Huachuan Machinery Co., Ltd.
- Contact nameRobbie Dou
- Phone86-532-85191579
- Address817#, haibin 6th Road,Jiaonan.Qingdao Qingdao,Shandong
