Electrical/ Gas/Oil Heating Type Rubber Tile Curing Press / Curing Machine

Name: Electrical/ Gas/Oil Heating Type Rubber Tile Curing Press / Curing Machine
Brand: QDHC
SKU: 122637823
Availability: InStock

US$ 1,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

QDHC

Qingdao Huachuan Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name QDHC

Model Number Customized

Voltage 220V-440V

Power(W) According to different machine

Dimension(L*W*H) According to different machine

Weight Customized

Certification CE/ISO9001

Warranty One year, One year

After-sales Service Provided Engineers available to service machinery overseas

Electrical/ Gas/Oil heating type rubber tile curing press / curing machine

Product Description

Technical Parameter:

Item	*XLB-D5505504 curing machine*
Total pressure	MN	0.50 (50 tons)
Hot plate size	MM	*55055060*
Plate clearance	MM	150
Working layer	layer	4
Hot plate quantity	Piece	5
Piston stroke	MM	400
Piston quantity	Set	1
Piston diameter	MM	200
Structure mode		Frame structure
Operation system		Manual operation
Working pressure	Mpa	1.65 (16.5kg/cm²)
Motor power	KW	2.2
Note: 1-The vulcanizing machine is mainly use to produce rubber tile, Each working layer equipped with two sets moulds, it can take turn vulcanization. Thereby improve production efficiency. 2-We also can according to the customers' requirement, and design/manufacture the non-standard type of the rubber tile press.
