Product Overview
flip up laptop
FSX – 14A is the latest research and development type of half rugged portable laptop solutions.The machine after test such as vibration, impact, falling, high and low temperature, aging,Suitable for general conventional indoor and outdoor environment,humanized industrial design to ensure that the product has the characteristics of high integration, portable, rugged.
The product integrates the rich I/O extension interface,equipped with high-performance 14 "backlit LCD screen and core module for processing,rechargeable battery and efficient power management software,The product has strong extend function,different needs can also provide customized service. Easy to integrate third-party software and hardware. It is the best solution for the military, public safety, on-site service and in the field of other special applications.
Product features
All aluminum alloy design
normal temperature widescreen 14"LCD, 1366x768 resolution(optional 1920x1080)
armored glass(optional)
resistive touch screen(optional)
19V~24VDC wide range of voltage input
Build-in 1*7800mAH lithium battery
Self-power supply battery management software
1*Mic-i;1*Line-in;1*Line-out;2*LAN; 4*USB3.0;1*DVI-I;1*HDMI;1*COM
Two expansion slot PCI(optional PCIe)
Product specification
| CPU | Socket G2 988B for: |
| 3rd Generation Intel® Core TM processors(22nm process technology) | |
| 2rd Generation Intel® Core TM processors(32nm process technology) | |
| Preloaded Intel I5-3320M 2.6/3.3G 4M(optional) | |
| RAM | Two 204-pin DDR3 SODIMM sockets |
| Preloaded DDR3 1600 4G Notebook Memory(optional) | |
| Chipset | Intel® HM76 Express chipset |
| Graphics card | Intel® HD Graphics 4000 |
| Expansion slot | PCI slot x 2(optional) |
| Display | LTN140AT26-H02X(14”;1366*768;-10℃~60℃,brightness 250nit)widescreen |
| Touchscreen | 14”resistive screen(optional) |
| Network interface | Realtek 8111DL PCI Express Gigabit LAN controller |
| Storage | SATA3 solid state disk 2.5" 120GB(optional) |
| Expansion interface | Mic-in x1;Line-in x1;Line-out x1;LAN x2; USB3.0 x4;DVI-I x1;HDMI x1;COM x1 |
| Environment | operating temperature:-10℃~55℃;Storage Temperature:-20℃~65℃ |
| Power input | 19~24VDC(adapter input) |
| Battery | 19~24VDC-IN;12VDC-OUT,7800mAH |
| Size | 370mmx300mmx84mm |
| Weight | 5.6KG |
| Type | flip up portable laptop |
Order information
FSX-14A
In addition to the standard products, also accept customers' special requirements of modified (for example add air outlet), also accept OEM/ODM orders
paper carton ocean transport
1 years tecnical service
Qingdao Fu shun Xing Electronics Technology Co., Ltd is a technology company specializing in the research, development and service of automatic intelligent control, visual image identification. The company promotes series products of portable computer, industrial tablet pc, reinforced anti-riot army-regulation computer, non-fan Embedded IPC, X-RAY foreign matter detector, basket washing machine, slicer and turnover washing machine. The products have been applied in the military industry, telecommunication, metallurgy, transportation, electricity, railway, aviation, communication, finance, network, medical treatment, machine manufacturing, precise instrument, food processing and other sectors extensively.
