One Layer Lower Water-cooled PP Film Blowing Machine

Name: One Layer Lower Water-cooled PP Film Blowing Machine
Brand: Donghailong
SKU: 122549967
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Film

Plastic Processed:

Donglong Plastic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Film

Plastic Processed PP

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Fujian, China

Brand Name Donghailong

Model Number XSJ55-FMX800L

Voltage 220/380V

Power(W) ~45kw

Dimension(L*W*H) 6.0*1.8*3.6m

Weight ~2700kg

Certification CE,TUV,SGS

Warranty 1 YEAR, 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Features & Specifications:

XSJ-L series lower water-cooled film blowing machine employs lower blowing and self-overflowing method to produce products. The product is features by high transparency, good printing performance and adhesive.

The extrusion system of the machine and the plasticization of the machine head have met the international advanced standard. Additionally, there are many types of equipment such as rotary machine head, static elimination and fully-automatic precise temperature control available for your choice. It is the ideal packing material for food, garment and other high grade products.

Main Technology Parameters

XSJ-L series lower water-cooled film blowing machine
MODEL NO.		XSJ45-FMX500L			XSJ55-FMX800L	XSJ65-FMX1000L
LAYER NUMBER		1
MAX. FILM WIDTH		mm		400	650	800
FILM THICKNESS		mm		0.02~0.12
OUTPUT		Kg/h		35	50	65
RAW MATERIAL		PP
EXTRUDER
SCREW DIAMETER	mm			Φ45	Φ55	Φ65
SCREW L/D				28:1		25:1
HEATER CAPACITY	kw			8.3	10.7	13.1
DRIVING MOTOR	kw			11	15	18.5
ROTATING DIE
DIE DIAMETER			mm	Φ 150	Φ 250	Φ400
HEATER CAPACITY			kw	4.5	8	10.5
WATER COOLING RING			cm	10,12,15,17,20 25,30,32,35,40	25,28,30,35,40 45,50,55,60,65	35,40,45,50,55 60,65,70,75,80
COOLING AIR BLOWER			kw	0.55	0.75
HAUL-OFF
DRIVING MOTOR			kw	1.5
TAKE-UP SPEED			m/min	10~55
WINDER DRIVE MOTOR			kw	2.2	3.3	4.1
TEMPERATURE CONTROL			point	6	7
WHOLE POWER WITH TOTAL MACHINE			Kw	~ 28	~ 40	~ 49
SHAPE SIZE			m	4.0 X 1.3 X 3.0	6.0 X 1.8 X 3.6	6.7 X2.5 X4.2
WEIGHT			t	~ 2.8	~ 3.8	~ 4.5
Correct specifications depend on the actual model all specifications are subject to change without prior notice
