Specifications
PE plastic film blowing machineblown film machine
with high quality and good price
different models for your choice
HDPE/LDPE/LLDPE Plastic Film Blowing Machine/Blown Film Line
Feature:
The machine is employed to produce plastic film made of low density polyethylene(LDPE), high density polyethylene(HDPE), linear low density polyethylene(LLDPE) and metallocene linear low density polyethylene(mLLDPE). The products are widely used in application of package of civil and industrial products such as food, garment, textile and daily necessities etc. The produces include vest bag, shopping bag, garment bag and food bag etc.
Main technical Parameters:
Model No. |
SJ35-FMS500P |
SJ45-FMS650P |
SJ50-FMS850P |
SJ55-FMS1100P |
SJ65-FMS1300P |
Layer Number |
Single Layer |
||||
Max. Folded Film Width |
400mm |
550mm |
800mm |
1050mm |
1200mm |
Film Thickness |
0.008~0.10mm |
0.015~0.10mm |
0.020~0.15mm |
0.020~0.15mm |
0.020~0.18mm |
Output |
15kg/h |
35kg/h |
50kg/h |
60kg/h |
80kg/h |
Raw Material |
HDPE,LDPE,LLDPE |
||||
Screw Diameter |
Φ35 mm |
Φ45mm |
Φ50mm |
Φ55mm |
Φ65mm |
Screw L/D |
28:1 |
||||
Die Diameter |
LDPE:100mm HDPE: 30mm, 50mm |
LDPE: 200mm HDPE: 50mm, 70mm |
LDPE: 200mm HDPE: 60mm, 80mm |
LDPE: 250mm HDPE: 60mm, 90mm |
LDPE: 300mm HDPE: 80mm, 110mm |
Take-up Speed |
10~70m/min |
10~70m/min |
10~70m/min |
10~70m/min |
10~70m/min |
The Total Power of the Machine |
~ 23kw |
~ 35kw |
~ 42kw |
~50kw |
~62kw |
Shape Size |
3.5*2.5*3.0m |
4.5*2.3*4.0m |
5.2*2.5*4.0m |
5.5*2.8*4.5m |
6.3*3.0*5.0m |
Weight |
~1500kg |
~2500kg |
~3000kg |
~3500kg |
~4200kg |
