Specifications
LDPE/HDPE Film Blowing Machine with double windersrotating die head
max. film width can be 2meters
Sell to Argentina Mexico
Features:
1) This pe blown film machine is designed to produce plastic film made of low density polyethylene (LDPE), high density polyethylene (HDPE), linear low density polyethylene (LLDPE).
2) It employs some new technologies like the most advanced heat running technology and special wind ring that is used to extrude the shaped mulch plastic film. The machine is designed reasonably and elegantly. It is small and is easy to operate and maintain. The product features with good plasticization, high physical and mechanical performance and strong tear resistance. With advanced technology and reasonable accessories, the machine is featured by high output, low energy consumption, good stability and reliability
Main Technology Parameters:
1) LAYER NUMBER: one layer
MAX. FILM WIDTH: 1600mm
FILM THICKNESS: 0.020-0.25 mm
RAW MATERIAL: HDPE/ LDPE/LLDPE
Output: 120kg/h(LD),100kg/h(HD)
2) EXTRUDER:
SCREW DIAMETER: Φ75mm
SCREW L/D: 28:1
HEATER CAPACITY: 20.7kw
DRIVING MOTOR: 45kw
3) DIE:
DIE DIAMETER: HDPE Φ110mm, Φ150mm,LDPEΦ400mm
HEATER CAPACITYHDPE: 6.8KW, LDPE: 11.35KW
COOLING AIR BLOWER: 5.5kw
4) HAUL-OFF:
DRIVING MOTOR: 2.2 KW
TAKE-UP SPEED: 10-50 m/min
WINDER DRIVE MOTOR: 6.6 KW
TEMPERATURE CONTROL: 6 units
WHOLE POWER WITH TOTAL MACHINE: About 95 KW
SHAPE SIZE: (L x W x H) 7.3 X3.5X7.5m
WEIGHT: About 6700KG
