Help CenterDL-R Series Two-line T-shirt Bag Making Machine
Related Products
-
DL-3Z Series Automatic Three-folding Bag Making MachineUS$ 2,000 - 50,000MOQ: 1 Set -
Plastic T-shirt Bag Making MachineUS$ 2,000 - 50,000MOQ: 1 Set
-
Shopping Plastic Bag Making MachineUS$ 2,000 - 50,000MOQ: 1 Set
-
DL-DAV Series Hot Seal And Cool Cut Impulse Sealing MachineNegotiableMOQ: 1 Set
-
DL-DAV Series Hot Seal and Cool Cut Impules Bag Sealing MachineUS$ 1,000 - 50,000MOQ: 1 Set
Features:
1,This machine is designed to produce t-shirt bags,U shape bags,etc,fully automatically.
2,With two lines,the production capacity will be increased.
3,The whole machine is controlled by servo motor ,thus the material will be conveyed smoothly and quickly.
4,With Janpan brand 'panasonic' elertric eyes,it has advatage of great qulity,sensitive to colors and catching colors accurately.
5,The whole machine adapts computer control system to set bag lenth,production speed,thus can reduce the waste and saving cost;feeding material,counting and sending out material automatically;the machine will aralm automatically when the machine is out of work,therefore it will be safe to operate.
Main technical parameters:
Model |
DL-R400x2 |
DL--R500x2 |
Max. Bag Width |
330x2mm |
430x2mm |
Max.Bag Length |
650mm |
650mm |
Bag Thickness |
0.013-0.025mm |
0.013-0.025mm |
Speed |
220x2(pic/min) |
220x2(pic/min) |
Total Power |
9kw |
10kw |
Size(L x W x H) |
5.4x1.65x1.55m |
5.4x1.85x1.55m |
Weight |
~2500kg |
~2700kg |
Ps:Correct specifications depend on the actual model all specifications are subject to change without prior notice. | ||
