Specifications
1. safety as a priority.2. easy to operate.
3. lower speed.
4. higher efficiency.
5. long lifetime.
Advantage of 10kW wind turbine power generator:
1. SCF Supercritical generator
Hummer’s 10kW wind turbine generator adopts SCF supercritical technology which won a gold award in the 37th Salon Eureka in Brussels. This technology significantly reduces generator’s weight and size down to 20% to 30% of the traditional one, and the production efficiency is 10% to 30% higher. This ensures that the generator functions perfectly in small wind condition.
2. SKF bearings
Hummer 10kW wind turbine generator adopts the SKF bearings which are produced by the renowned bearing manufacturer in the world, with the perfect internal geometric structure, known for its life-time endurance and reliable quality. As well as enabling smooth and quiet rotation, they also perform an important function by taking on the motor's load
3. PLC integrated with Siemens module
Hummer 10KW wind turbine generator’s controlling system adopts the smart touch-screen PLC (Programmable Logic Controller) which is integrated with Siemens controlling unit. The PLC will alarm and adjust the abnormal running status of the wind turbine automatically both timely and efficiently. Siemens module offers high reliability to our PLC and its customers worldwide can testify for that.
4. Low noise
The design of the rotor blade of Hummer 10KW wind turbine generator absorbs the highlights of the small aircraft’s airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.
5. Triple braking protection
Hummer 10kW wind turbine generator adopts the triple braking protection system, which are the yawing mechanism, the electromagnetic braking system and the hydraulic braking system to regulate the rotation of the wind turbine. It is easy and convenient to shut down the whole system both manually and automatically.
Structure of wind turbine power generator 10KW:
Technical Parameter of 10kW wind turbine power generator :
Rated power (W) |
10000 |
Maxi mum output power (W) |
15000 |
Battery bank voltage (Vdc) |
240 |
System output voltage (Vac) |
110/220V single phase or 380V three phase |
Start-up wind speed (m/s) |
3 |
Rated wind speed (m/s) |
10 |
Working wind speed (m/s) |
3-25 |
Survival wind speed (m/s) |
50 |
Generator type |
Permanent Magnet Alternator |
Generator weight (kg) |
287 |
Blade material/quantity |
GRP/3 |
Blade diameter (m) |
8.0 |
Speed regulation method |
Yawing+Electromagnetism braking (Optional hydraulic braking) |
Shutting down method |
Manual+Automatic |
Diagram of 10kW wind turbine power generator system:
Project Cases of 10kW wind turbine power generator for business:
Certificate of Hummer 10kW wind turbine power generator:
