Help CenterHummer Self Support 3kw Wind Generator for Off-grid Application
Related Products
-
100kw Permanent Magnet Alternator Wind Turbine (H20.8-100kW)US$ 90,100 - 90,200MOQ: 1 Set -
60kW Turbina Eolica Generatore Eolico per L'ItaliaUS$ 100,000 - 130,000MOQ: 1 Set
-
Reliabe and Quiet Running Wind Turbine Generator 3kw for Home /farm/base StationUS$ 5,000 - 9,000MOQ: 1 Set
-
Hot Sale Permanent Magnet Generator Wind Turbine 3kw/windmill/wind Power Generator 3KW for Power UseUS$ 5,000 - 9,000MOQ: 1 Set
-
Alternative Energy Wind Power 50kW Turbine BladeUS$ 46,950 - 52,800MOQ: 1 Set
Specifications
15-20 years service lifeSiemens PLC control
Touch screen, realtime monitor
Grid-tied and off-grid option
CE certificated
Hummer self support 3kw wind power generator for off-grid application Specifications
Rated power (W) |
3000 |
Maximum output power (W) |
4500 |
Battery bank voltage (Vdc) |
48v |
System output voltage (Vac) |
110/220 |
Start-up wind speed (m/s) |
2.5 |
Rated wind speed (m/s) |
10 |
Working wind speed (m/s) |
3-25 |
Survival wind speed (m/s) |
50 |
Generator efficiency |
>0.8 |
Wind energy utilizing ratio (Cp) |
0.4 |
Generator type |
Permanent Magnet Alternator |
Generator weight (kg) |
71.8 |
Blade material/quantity |
GRP/3 |
Blade diameter (m) |
Φ3.8 |
Speed regulation method |
Yawing+Electromagnetism braking (Optional hydraulic braking) |
Shutting down method |
Manual+Automatic |
Key Features
1high efficiency with 7 National Patents
2Lowe noise and long service life with 2 SKF bearings
3Siemens PLC control system and touch screen with intelligent control
4Can be solar wind hybrid use in rural place
5Sound level-lower noise below 45dbs
FAQ
Siting choose
Guy tower/free standing tower/ hydraulic tower 39ft (12m)
Fumigation-free packing
Off-grid application:An off-grid application is any dwelling or outbuilding that is powered by a battery system and is not connected to the utility, such as a remote home, cabin or shed
Battery suggestion :12V150AH/200AH/15pcs
