10KW Wind Generator System Netsh Wlan Set Hostednetwork Mode=allow Ssid=test Key=0123456789
US$ 7,700 - 35,000
MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Hummer
Model Number:
H8.0-10KW
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HAWT 10KW Small Wind Turbine Grid Tied for Telecom Tower Rural SchoolUS$ 7,700 - 35,000MOQ: 10 Sets -
10KW Small Wind Turbine System HouseholdUS$ 7,700 - 35,000MOQ: 10 Sets
-
Independent Power Generator off Grid SystemUS$ 475 - 499MOQ: 1 Set
-
Windmill Generator 1000W for Rural Power ElectricityUS$ 830 - 899MOQ: 1 Set
-
Small Wind Generator 1000W for Remote ElectricityUS$ 830 - 999MOQ: 1 Set
Place of Origin
Anhui, China
Brand Name
Hummer
Model Number
H8.0-10KW
Type
Wind Power Generator
Specifications
CE and UL certification10%~30% efficiency higher
1/3~1/5 smaller and lighter
PLC control system.
10KW Wind power generator system widely used in:
Housing and factory and farm Telecommunication Station TV Transfer Station Monitoring Station (military, hydrology, observatory) Water-pumping Station
Hummer 10kW wind generator system can be applied in both on-grid and off-grid systems. The output can be single-phase or three-phase AC and can drive a load below 20kW.
10KW Wind power generator system Specification:
| Rated power (W) | 10000 |
| Maximum output power (W) | 15000 |
| Charging voltage (V) | DC 240 |
| Blade quantity | 3 |
| Rotor blade material | GRP |
| Rotor blade diameter (ft.) | 26 (8.0m) |
| Start-up wind speed (mph) | 7 (3.0m/s) |
| Rated wind speed (mph) | 22 (10.0m/s) |
| Rated rotating rate (r/min) | 200 |
| Wind energy utilizing ratio (Cp) | 0.40 |
| Generator output | Frequency conversion AC |
| Rated charging current (A) | 41.7 |
| The maximum charging current (in a short time) (A) | 65 |
| Output AC frequency (Hz) | 0~280 |
| Generator efficiency | >0.85 |
| Free standing tower diameter (in.) | 35.4*Ø24.8 (900*630mm) |
| Tower height (ft.) | 49 (15m) |
| The weight of generator (lb) | 633 (287kg) |
| Suggested Battery (Ah) | 600/800 |
