Help CenterHigh Efficiency 5KW/10kW/20kW Dynamo Generator Wind Turbine Generator Free Energy System With CE/ISO/UL
Related Products
-
5KW Wind Turbine Generator/windmill/wind Power Generator/permanent Magnet GeneratorUS$ 4,000 - 8,000MOQ: 1 Set -
Wind Turbine 5KW Small Size Wind Generator CE and ISO9001US$ 4,000 - 8,000MOQ: 1 Set
-
5000W Wind Geneator Wind Turbine Low Wind High Efficiency Eolico WindmillUS$ 5,000 - 10,000MOQ: 1 Unit
-
2013 Newest 5kw Horizontal Axis Rooftop Wind Turbines Home UseUS$ 7,400 - 12,000MOQ: 1 Set
-
Low Rpm 5KW Wind Turbine Wind Power Generator System for Telecom/monitoringUS$ 4,000 - 11,000MOQ: 1 Piece
Hummer H6.4-5kw Basic Technical Parameters
Rated power (W) 5000
Maximum output power (W) 7500
Charging voltage (V) DC 240
Blade quantity 3
Rotor blade material GRP
Rotor blade diameter (ft.) 21 (6.4m)
Start-up wind speed (mph) 6 (2.5m/s)
Rated wind speed (mph) 22 (10.0m/s)
Rated rotating rate (r/min) 240
Wind energy utilizing ratio (Cp) 0.4
Generator output Frequency conversion AC
Rated charging current (A) 20.8
The maximum charging current (in a short time) (A) 32
Output AC frequency (Hz) 0~360
Generator efficiency >0.8
Free standing tower diameter (in.) 19.5*7.3 (Ø495*Ø185mm) (2pcs)
Guy tower diameter(in.) 8.7*78.7*0.2 (Ø220*3000*6mm)(4pcs)
Tower height (ft.) 39 (12m)
The weight of generator (lb) 324 (147kg)
Suggested Battery (Ah) 400/600
