Low Speed Magnet Generator 100kW Wind Turbine

Name: Low Speed Magnet Generator 100kW Wind Turbine
Brand: Hummer
SKU: 122495441
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Hummer

Model Number:

H20.8-100KW

Anhui Hummer Dynamo Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Hummer

Model Number H20.8-100KW

Type Wind Power Generator

roduct Information

Main technical data of low speed alternator 100kW wind turbine:

Configuration	3 Blades, Horizontal axis, Upwind
Rotor Diameter	20.8 m
Direction of Rotation	Clockwise looking upwind
Blade Material	Fiberglass reinforced composite
Rated Power	100KW
Maximum Output Power	100kW
Battery Bank Voltage	480 Vdc
System Output Voltage	380 Vac three phase
Cut-in Wind Speed	3 m/s
Rated rotating rate	60 r/min
Working Wind Speed	3-25 m/s
Survival Wind Speed	60 m/s
Alternator	Permanent magnet alternator, SCF technology
Alternator Weight	4000 kg
Generator Efficiency	>0.93
Energy monitoring & User control	Siemens PLC controller with touch screen
Gearbox	None, Direct drive with front generator design
Over Speed Regulation	Auto Yawing & Hydraulic Braking & Pitch control
Shutting Down Method	Manual & Automatic electromagnetism Braking & Hydraulic Braking
Warranty	2 years

Products Features of alternator wind turbine:

SCF (Supercritical Generator Technology) generator technology as core, Feature is extremely light ,small,fasting,stable with higher power efficiency .
Adopt NSK bearings, which have a 15 years life span without maintenance.
Smart Intelligent yaw shaft system has designed with sensor to detect speed,Rpm,angle ,tempreture of generator, speed,direction of wind etc.
PLC controller system(Smart and lntelligent) with touch screen, which can automatically seek wind direction, drifts off the blades from strong wind direction to protect the system and constantly monitor generator working status, Monitoring rotation speed, generator temperature, wind speed and direction etc. All data will be transmitted to control center and easy view control with the touch screen.
One international patents, Six National patents and ensure the perfect performance.
