Specifications
1.Safety as a priority.2.Easy to operate.
3.Lower start up wind speed.
4. Higher efficiency.
Product advantages:
1. SCF Supercritical generator
Hummer’s 60kW wind generator adopts SCF supercritical technology which won a gold award in the 37th Salon Eureka in Brussels. This technology significantly reduces generator’s weight and size down to 25% to 30% of the traditional one, and the production efficiency is 25% to 30% higher. This ensures that the generator functions perfectly in small wind condition.
2. NSK bearings
Hummer 60kW wind turbine adopts the NSK bearings which are produced by the renowned bearing manufacturer in the world, with the perfect internal geometric structure, known for its life-time endurance and reliable quality. As well as enabling smooth and quiet rotation, they also perform an important function by taking on the motor's load.
3.PLC integrated with Siemens module
Hummer 60kW wind turbine’s controlling system adopts the smart touch-screen PLC (Programmable Logic Controller) which is integrated with Siemens controlling unit. The PLC will alarm and adjust the abnormal running status of the wind turbine automatically both timely and efficiently. Siemens module offers high reliability to our PLC and its customers worldwide can testify for that.
4. Low noise
The design of the rotor blade of Hummer 60kW wind turbine absorbs the highlights of the small aircraft’s airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.
5. Triple braking protection
Company strong strength:
High Technology--Won gold award of 37th World Invention Exposition in Brussels Eureka WITH 7 Patents;
High Quality--CE,BV,ISO Certificate;
Hight Service--Long time warranty with Unique Service department
60KW WIND TURBINE PARAMETERS
Model |
HUMMER-60kW |
Rated power(W) |
60000 |
Maximum output power(W) |
80000 |
Start-up wind speed (m/s) |
2 |
Rated wind speed (m/s) |
11.5 |
Working wind speed(m/s) |
2.5-25 |
Survival wind speed(m/s) |
50 |
Rated rotating speed (r/min) |
140 |
Maximum rotating speed (r/min) |
200 |
Generator efficiency |
>0.92 |
Generator type |
Permanent Magnet Alternator |
Generator weight (kg) |
1500 |
Blade material/ quantity |
GRP/ 3 |
Blade diameter(m) |
Ø14.4 |
Speed regulation method |
Yawing+ electromagnetism braking+ hydraulic Braking |
Shutting down method |
Manual Operation+ Automatic |
Currently we offer wide range:
1) 500W-100kw wind turbine Off-grid /Grid-tied;
2) 400W-600W Wind-Solar LED street light and traffic light;
3) Wind-Solar hybrid generating system;
4) Wind-Solar-Diesel hybrid generating system.
