Specifications
maglev vertical axis wind turbine generator1. quiet running.
2. easy for manual operation.
3. remote control and monitoring
Hummer maglev vertical axis wind turbine generator New Energy Generator
Advantage of Hummer wind turbine generator :
1. SCF Supercritical generator
Hummer’s wind generator adopts SCF supercritical technology which won a gold award in the 37th Salon Eureka in Brussels. This technology significantly reduces generator’s weight and size down to 20% to 30% of the traditional one, and the production efficiency is 10% to 30% higher. This ensures that the generator functions perfectly in small wind condition.
2. NSK bearings
Hummer 10kW wind turbine adopts the NSK bearings which are produced by the renowned bearing manufacturer in the world, with the perfect internal geometric structure, known for its life-time endurance and reliable quality. As well as enabling smooth and quiet rotation, they also perform an important function by taking on the motor's load
3. PLC integrated with Siemens module
Hummer wind turbine’s controlling system adopts the smart touch-screen PLC (Programmable Logic Controller) which is integrated with Siemens controlling unit. The PLC will alarm and adjust the abnormal running status of the wind turbine automatically both timely and efficiently. Siemens module offers high reliability to our PLC and its customers worldwide can testify for that.
4. Low noise
The design of the rotor blade of Hummer wind turbine absorbs the highlights of the small aircraft’s airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.
5. Triple braking protection
Hummer 10kW wind turbine adopts the triple braking protection system, which are the yawing mechanism, the electromagnetic braking system and the hydraulic braking system to regulate the rotation of the wind turbine. It is easy and convenient to shut down the whole system both manually and automatically.
Structure of wind turbine generator :
Main Technical Parameter of wind turbine generator 10KW:
Rated power (W) |
10000 |
Maxi mum output power (W) |
15000 |
Battery bank voltage (Vdc) |
240 |
System output voltage (Vac) |
110/220/380 |
Start-up wind speed (m/s) |
3 |
Rated wind speed (m/s) |
10 |
Working wind speed (m/s) |
3-25 |
Survival wind speed (m/s) |
50 |
Generator efficiency |
>0.85 |
Wind energy utilizing ratio (Cp) |
0.4 |
Generator type |
Permanent Magnet Alternator |
Generator weight (kg) |
287 |
Blade material/quantity |
GRP/3 |
Blade diameter (m) |
8.0 |
Speed regulation method |
Yawing+Electromagnetism braking (Optional hydraulic braking) |
Shutting down method |
Manual+Automatic |
wind turbine generator system:
Project Case of wind turbine generator :
wind turbine generator widely used in:
Housing and factory and farm
Telecommunication Station
TV Transfer Station
Monitoring Station (military, hydrology, observatory)
Water-pumping Station
Shipping
FAQ of wind turbine generator :
1.What's the delivery time ?
15 working days after your deposite
2.What's the warranty and service?
Five years for generator system and 2 years for other parts
3.How long are we specialized in wind turbine industry?
From 1993 till now. Expert enterprise and a well-known professional manufacturer
4.What's the unique feature about Hummer?
small, light, high efficiency, low noise with SCF generator technology
smart control system with touch screen
high wind protection
All above features with 7 patents, ranging from 500w to 100kw medium and small-sized wind turbines
5.Quality?
Strict factory inspction, SCF generator and inverter certified by CE ,UL,ETL, exported to more than 90 counties..
Certificate of wind turbine generator :
Any Question, Pls Feel Free To Contact Hummer Dynamo!
