Specifications
1.120-220m/min high speed prodution.2.Coating average,save glue.
3.Lifting feeding and lifting laminating.
4.Easy operation.
Video:
/v_show/id_XMjg5NzQwMDIw.html
1.Application:
Suitable for coating thermal paper ,carbonless paper,carbon paper.
2.Feature
- 1.Smooth glue,twice gravure glue.
- 2.HIgh voltage calender,three-type roller to make sure the smooth paper and no wrinkle.
- 3.Duplex unwinding and rewinding
- 4.Cloth storage and auto connect the paper .
- 5.Auto temperature control to suit refresh material.
Side view:
Comma coater:
Silicon coater:
Lifting feeding unit:
Lifting laminating unit:
2.Technical parameters:
Type |
impulse type,electric heated,arch form |
Width of basis material |
Min.600-Max.1100mm |
Roll width |
1250mm |
Diameter of basis material |
max.unloading 800mm |
Coating material |
water-based and oil-based glue |
Coating average |
dry glue≤ 0.0015mm |
Rewidning brim trimness |
trimness error≤ 3mm |
Width of basis material |
500-8000m |
Coating way |
reticulate-type glue,straight scratch on the plastic |
Mechanical speed |
40m/min(Max.) |
Coating speed |
30m/min(Max.) |
Temperature |
min.10 degree C |
Oven temperature |
Max.160 degree |
Heating resource |
Electric heater |
Compressed air |
5kg/cm2 |
Power |
3 phase,380v,50HZ |
