Axial Flux Permanent Magnet Generator(AFPMG320-0.5kW/200rpm)
US$ 1,000 - 2,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Hiest
Model Number:
AFPMG320-0.5kW/200rpm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Axial Flux Permanent Magnet Generator(AFPMG260-0.3kW/300rpm)US$ 1,000 - 2,000MOQ: 1 Unit -
Axial Flux Permanent Magnet Generator(AFPMG260-0.2kW/200rpm)US$ 1,000 - 3,000MOQ: 1 Unit
-
Axial Flux Permanent Magnet Generator(AFPMG560-1.5kW/100rpm)Inner RotorUS$ 1,000 - 3,000MOQ: 1 Unit
-
Axial Flux Permanent Magnet Generator(AFPMG560-3.0kW/100rpm)Inner RotorUS$ 1,000 - 4,000MOQ: 1 Unit
-
Axial Flux Permanent Magnet Generator(AFPMG450-1.0kW/120rpm)US$ 1,000 - 3,000MOQ: 1 Unit
Place of Origin
Zhejiang, China
Brand Name
Hiest
Model Number
AFPMG320-0.5kW/200rpm
Type
Other, Wind Power Generator, Axial flux permanent magnet generator
Specifications
High efficiency at low speed;Small dimension and light weight;Very small maintenance costs;small starting torque;no noise;clean.- Standard Parameter and Technical Curves
- Constructions and Materials
- Advantageous Features
High efficiency at low speed
No mechanical drive losses, no rotor copper losses due to the permanent magnet excitation and no stator eddy current losses in the ironless (coreless) stator.The efficiency of AFPMG, depending on the model, is up to 90%.
Small dimension and light weight
Axial flux permanent magnet generator(AFPMG) is uniquely lightweight and compact, construction is simple. The generators use much less metal in their construction, while also being highly durable and having a long life.
The generator's small weight and dimensions make it possible to reduce the size and price of the whole wind turbines.
The high specific capacity (output capacity per unit weight) significantly outperforms those from competing producers. This means that with similar dimensions and weight.
Very small maintenance costs
Axial flux permanent magnet generator(AFPMG) is direct drive, no gearbox, oil-free system, low temperature rise.The highest energy efficiency at low speeds in the industry means that the generators can support any type of wind turbine with the widest range of wind speed. The use of air-cooling reduces maintenance costs and also significantly strengthens the autonomy of power units.
Very small starting torque
Axial flux permanent magnet generator(AFPMG) have no cogging torque and torque ripple, so the starting torque is very low, for direct-drive small wind turbine (SWT), the starting wind speed is less 1m/s.
Superior reliability
Axial flux permanent magnet generator(AFPMG) has very lower noise, less vibration, no mechanical belt, gear or lubrication unit, long life.
Environmentally friendly
The 100% environmentally clean technology and materials used in production of Axial flux permanent magnet generator(AFPMG) during its long service life and the future recycling are absolutely harmless for the environment.
- Main Applications of Axial flux permanent magnet generator
- Small wind generators(SWT)
- Small electrical generators driven by gasoline or diesel engines
- Electric vehicle drive machines, as motor and generator.
- Hydro Power
- Typical Models
- OptionsRated power: 0.1KW-15.0KWRated speed: 100RPM-1200RPMRated voltage: 14VDC-400VACGenerator outer diameter: 110mm-770mmWe can customize products according to customer requirementsWe can do OEM (Original equipment manufacturer) for customers
-
Checklist Category1. Dimension and tolerances2. Output power, voltage and RPM3. Insulation resistance examination4. Starting torque5. Output wire (Red, white, black, green/earth)
-
Operating Instructions1. Working condition: under an altitude of 2,500 meters, -30 ° C to +50 ° C2. Before installation, gently turning the shaft or housing to confirm rotation flexibility, no abnormal sound.3.Output of Axial flux permanent magnet generator(AFPMG) is three-phase, three-wire output, before installation, use 500MΩ Megger tocheck the insulation resistance between the output wire and case, should not be less than 5 MΩ4. If Axial flux permanent magnet generator(AFPMG) is inner rotor generator, in the installation process, should ensure that the locking screw in place, it is very important.
- Warranty: 2-5 years
