Outdoor 65degree-18dBi Base Panel Antenna(850/900MHz) for Donor or Emission Signal
US$ 1 - 99
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
KINGTONE
Model Number:
KTTD-15065-08V
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Outdoor 65degree-15dBi Base Panel Antenna(806-960 MHz) for Donor or Emission SignalUS$ 1 - 99MOQ: 10 Pieces -
Strong Magnetic Base Mount,with Steel Housing and Strong Magnet for Vehicle Two-way Radio Communication, With RG58UUS$ 1 - 10MOQ: 10 Pieces
-
Tilt Angle Adjustable Mount for Mobile Radio/boat AntennaNegotiableMOQ: 1 Piece
-
Professional Omni Directional Fiberglass Antenna ,2.4/3.5GHz Fiberglass AntennaNegotiableMOQ: 50 Pieces
-
VHF MC - 101 High Gain Diamond MC101 Commercial High Gain Antenna With Cutting ChartUS$ 1 - 10MOQ: 1
Place of Origin
Fujian, China
Brand Name
KINGTONE
Model Number
KTTD-15065-08V
Specifications
18dBi Base Panel Antenna(850/900MHz)Frequency Range 806-896(MHz) 890-960(MHz)
Input Impedance 50
VSWR <1.5
outdoor 65degree-18dBi Base Panel Antenna(850/900MHz) for donor or emission signal
Electrical specifications
Model |
KTTD-18065-08V |
KTTD-18065-09V |
Frequency Range |
824-896(MHz) |
890-960(MHz) |
Input Impedance |
50(Ω) |
|
VSWR |
<1.5 |
|
Gain |
18(dBi) |
|
(3dB)HPBW |
65°H-plane 8°E-plane |
|
F/B |
>25(dB) |
|
Maximum Power |
500(W) |
|
Polarization |
Vertical Polarization |
|
PIM |
<-107(dBm) |
|
Connector Type |
7/16 or N-K |
|
Lighting Protection |
Direct Ground |
|
Ambient temperature |
-40°C— +60°C |
|
|
Mechanical specifications | ||
Radome Material |
ABS |
|
Radom Colour |
Ashen |
|
Wind Velocity |
200(km/h) |
|
Height/Width/Depth |
2300/280/125(mm) |
|
Weight |
17(kg) |
|
Hold Pole Diameter |
Φ50-Φ114(mm) |
|
