Home > Products > H Beam Production Line > Box Beam Build up line, Box Beam Built up line
Box Beam Build up line, Box Beam Built up line
- 0 per Month
- Shanghai
- T/T
Product Details
Condition: | New | Use: | H Beam Flange | Place of Origin: | Jiangsu, China |
Brand Name: | Friendship Machinery | Model Number: | HYJ Series | Certification: | CE, ISO |
Warranty: | One year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. Main introduction
Hydraulic flange straightening machine is used for the angle distortion straightening of the H-beam with large thickness. Hydraulic cylinder presses from down side to up side, which has strong force and high driving torque and with good straightening efficiency and good quality. This machine is widely used for the fire electric furnace, heavy duty steel structure construction, steel bridge, water power industry.
h-beam machine, h-beam steel, h-beam welding line, h-shape steel, h-beam production machine, h-beam production line, h-beam straightening machine, h-beam fabrication line, spot welding machine for h-beam, steel structure equipment, steel welding line, welding line, welding production line, steel welding production line, steel production line, I-beam production line.
2. Machine specifications
Type | HYJ-60 | HYJ-80 |
Width of flange | 180-800mm | 600-1000mm |
Thickness of flange | ≤60mm | ≤80mm |
Minimum height of the web | 350mm | 500mm |
Material | Q345A | Q235Mn |
Straightening speed | 6.37m/min | 6m/min |
Motor power | 37kw | 44kw |
Overall dimension | 3120×4100×2100mm | 4700×25001×2400mm |
Weight | 25000kg | 28000kg |
Structure of H beam hydraulic straightening machine simple, with convenient and reliable operation which used for semi-automatic H-beam production line
a. Hydraulic type straightening with strong straightening force and high automation which usually used for full automatic H-beam production line
b. Straightening and powered roller: nice alloy steel, which are made after heat treating with long lifespan usage
c. Hydraulic type straightening machine used for angle distortion straightening of H-beam with large thickness
d. Hydraulic cylinder presses from down side to up side, which strong force and high driving torque and with nice straightening efficiency |
