Mechanical panel bending machine
1. Technical parameters
No. |
Item |
Specification |
1 |
Pipe diameter |
φ22-φ63.5mm |
2 |
Maximum width of pipe panel |
1600mm |
3 |
Maximum clamp power |
2 T |
4 |
Largest bending angle |
α = 150 ° |
5 |
Bend radius |
R = 180-450mm |
6 |
Bending speed |
≈ 0.26r/min |
7 |
Motor |
7.5kw |
2. Control system
Touch screen, PLC, remove control switch. Bending the welded pipe panel into the required size, motor as power, with the advantages of simple structure, ease of operation.
3. Composition of equipment
- Mechanical components are composed Machine body, driven system mechanical bending system.
- Main body is welded steel structure, tempered by big oven to remove strength.
- Design and make according to China national standard, to ensure machine durability.
- Use good quality steel tampered, quenched after processing, make machine have enough rigidity and toughness.
- Electrical control system is composed of touch screen, PLC, remote control and so on.
-Touch screen show current angle, can set bending angle. Angle is controlled by PLC, make sure bending accuracy reach 0.1 degree.
