Boring Machine T8018A ,T8018B, T8018C
US$ 7,400 - 7,700
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Production Capacity:
5000sets/year
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Production Capacity
5000sets/year
Place of Origin
Anhui, China
Brand Name
WHITE EAGLE
Model Number
T8018A T8018B T8018C
Voltage
As buyer's need
Power(W)
3 Kw
Dimension(L*W*H)
2000x1225x2120mm
Weight
2100/2300kgs
Certification
ISO9001
After-sales Service Provided
No overseas service provided
Boring machine T8018A ,T8018B, T8018C
The machine is mainly used for boring the cylinder hole of internal combustion engine & inner hole of cylinder sleeve of cars or tractors, and also for other machine element hole.
T8018A: mechanical-electronic drive and spindle speed frequence changed speed variation.
T8018B: mechanical drive
T8018C: used for processing special heavy motor cylinders.
| Model | T8018A | T8018B | T8018C |
| Processing Diameter | Φ30mm~Φ180mm | Φ42mm~Φ180mm | |
| Max. Boring Depth | 450mm | 650mm | |
| The Rotational Speed of Spindle | 140-610 | 175;230;300;350;460;600 | |
| Spindle Feed | 0.05, 0.10, 0.20 | ||
| Maching Power | 3.75kw | Main Motor:YD100L2-4/2,1400/2800rpm,2.4/3kw; Motor for Quick-Moving:Y802-4,1400rpm,0.75kw | |
| Overall dimensions (L*W*H) | 2000×1235×1920mm | 2680×1500×2325mm | |
| Packing dimensions (L*W*H) | 1400×1400×2250mm | 1578×1910×2575mm | |
| N.W/G.W | 2000/2200Kg | 3500/3700Kg | |
