flexible graphite sheet
- 60 Ton / Tons per Month
- Shang or Ningbo
- T/T
- IG-010 Double layer tinplate Single sided tanged sheet graphite composite sheet
- IG-009 tinplate Single sided tanged sheet graphite composite sheet
- IG-008 multi-layer stainless steel wire mesh graphite composite sheet
- IG-007 Reinforced Graphite Composite Sheet with multi-layer stainless steel (304 l, 316 l) tanged sheet
- IG-006 multi-layer tinplate tanged sheet graphite composite sheet
- IG-005 graphite reinforced composite sheet (lined with stainless steel wire mesh)
Product Details
Place of Origin: | Hubei, China | Brand Name: | hengda graphite | Model Number: | HDS101 |
Type: | Flexible Sheet | Thickness: | 0.2~1.1mm | C Content (%): | 99% |
Product Description
Specifications
flexible graphite sheet1)made by high pure graphite powder
2)thichness:0.2~1.1mm
3)C:more than 99%S:less than 1200ppm
Description
Flexible graphite sheet, namely flexible graphite roll, is compressed by expanded pure graphite. It can be machined into sheet or tape according to the request of customer. It is widely used as the raw material of reinforced graphite sheet, spiral wound gasket, graphite ring, graphite packing, etc.
Available specification
Width: 1000mm, 1020mm
Thickness: 0.2~1.1mm
Long: 50~100Mtr
Technical data
Density | 1.0g/cm3 |
Density Tolerance | ±0.05 g/cm3 |
Thickness Tolerance | ±0.03mm |
Carbon Content | 99% |
Ash Content | ≤1% |
Chloride content | ≤80ppm |
Sulphur Content | ≤1200ppm |
Working Temperature | -200 to +3300 Non-Oxidizing |
-200 to +500 Oxidizing | |
-200 to +650 Steam | |
Tensile Strength | ≥4Mpa |
Compressibility | 40 45% |
Recovery | ≥20% |
Ignition Loss | Less than 1%(450) |
Less than 20%(650) | |
PH | 0-14 |
